Space Requirements

TABLE 1
Dimension
Width
Depth
Height
Weight
Related Information
"Space Requirements" on page 16
■
"Rack Requirements" on page 40
■

Space Requirements

The Oracle Server X5-2 is a 1 rack unit (1U) server. For physical dimensions, see
Physical Specifications" on page
The server can be installed into a four-post rack cabinet that conforms to ANSI/EIA 310-D-
1992 or IEC 60927 standards, such as Oracle's Sun Rack II. All Oracle racks have the same
space requirements. The specifications for Oracle's Sun Rack II are listed in the following table.
TABLE 2
Requirement
Usable rack units
Height
Width (with side panels)
Depth Model 1242
Depth Model 1042
Weight Model 1242
Weight Model 1042
Maximum dynamic load
†
Depth is measured from front door handle to rear door handle.
The minimum ceiling height for the cabinet is 230 cm (90 inches), measured from the true floor
or raised floor, whichever is higher. An additional 91.4 cm (36 inches) is for top clearance. The
space above the cabinet and its surroundings must not restrict the movement of cool air between
16 Oracle Server X5-2 Installation Guide • January 2021
Oracle Server X5-2 Physical Specifications
Server Specification
Server chassis
Maximum overall
1-rack unit (1U) nominal
Fully populated server
15.
Sun Rack II Models 1242 and 1042 Specifications
Specification
42
199.8 cm (78.66 inches)
60 cm (23.62 inches)
†
120 cm (47.24 inches)
†
105.8 cm (41.66 inches)
150.6 kg (332 lbs)
123.4 kg (272 lbs)
1005 kg (2215 lbs)
Measurements
43.65 cm (17.19 inches)
73.7 cm (29 inches)
4.26 cm (1.68 inches)
18 kg (40 lbs)
"Server
