Wide-Coverage Internet Repeater Enhancement System
WIRES-X Portable Digital Node Function
Instruction Manual
The C4FM digital transceivers that support the Portable Digital Node Function are
FT3D, FT2D, FTM-400XD/D, FTM-100D and FTM-300D. (As of May 2020)
Other C4FM digital transceivers do not require WIRES-X user registration and may
immediately enjoy Internet communications by connecting to a WIRES-X local node
that is within radio range.
