data
(cc)-
Comments
Compressed Print Density Fonts provide six other fonts with
higher density print characteristics. See "Fonts, Compressed
Print Density" on page 85.
Each of the three pitches, 10 cpi, 12 cpi, and 15 cpi (measured in
characters per inch, cpi) produce non-expandable characters 0.1-
inch high and 3, 4, or 5 dot columns wide with a one-dot column
intercharacter spacing.
The 7 cpi font produces non-expandable characters 0.2-inch high
and 0.15-inch wide with a 2-dot column intercharacter spacing at
approximately 7 cpi.
You can select any specific font from any of the four
alphanumerics commands using the Font Parameter (special
combinations of the alphanumeric command height and width
parameters) as described in Table 10.
The Rot. Char Size option setting (from the front panel menu)
determines if rotated (clockwise / counter-clockwise), expanded
characters have a different size than an unrotated character with
the same size parameters ("Adjusted") or the same size ("Not
Adjusted"). The previous VGL version always operated in the
Adjusted mode.
The Adjusted mode reflects rotating a fixed 5x7 cell character on
a 60x72 dpi, non-symmetrical printer. The Not Adjusted mode
reflects rotating on a symmetrical dpi printer.
Impact Printer
Font Size Character Dimensions*
(Vert X Horiz)
7 cpi 14 dots (V) X 8 dots
10 cpi 7 dots (V) X 5 dots
12 cpi 7 dots (V) X 4 dots
15 cpi 7 dots (V) X 3 dots
* 10, 12, and 15 cpi use an intercharacter spacing of one dot position. The
elongated font uses an intercharacter spacing of two dot positions. Vertical
by horizontal dimensions above are based on the 60 X 72 dpi dots produced
on line matrix printers.
The data characters for printing in the rotatable
font.
Graphics Mode CR. Enter the SFCC for your VGL
configuration immediately followed by - to end the
command sequence.
Table 10. Rotatable Fonts
Alphanumeric Command
Font Parameter Value
Fonts, Rotatable
00,00
01,01
00,01
01,00
