Further Welding Parameters - EWM Taurus 551 Basic FDG Operating Instructions Manual

Design and function
MIG/MAG welding
5.2.3

Further welding parameters

Display
34
ENTER NAVIGATION
0
l
B
B
B
B
Setting/selection
Dynamic correction
•
Increase value > harder arc
•
Decrease value > softer arc
Gas pre-flow time
Gas post-flow time
Correct wire burn-back
If too high a value is set, a large ball will form at the tip of the wire electrode (bad re-
ignition) or the wire electrode sticks to the contact tip. If too low a value is set, the wire
electrode sticks to the weld pool.
•
Increase value > increase wire burn-back
•
Decrease value > decrease wire burn-back
Wire creep
A
B
A
A
A
A
A
Figure 5-13
EXIT
3 s
099-005149-EW501
11.08.2016
