Wiring Diagram - Directed DIRECTWIRE DIRECTECHS 933.TL14 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Body ECU Connector
(lower conn. left side
of steering column)
2
13 12 11 10
21 20 19
Refer to the
Starter disable connection
section for relay and
connector details.
(-) Parking Light: Blue/Black
Headlight Switch
or Green, pin 3
9 8
18 17 16 15 14 13 12 11 10
40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24
Autolight: White
or Yellow, pin 5
SIL Data:
Blue, pin 7
1 8
9 16
OBDII Diagnostic Connector
7 933.TL14 1.02.198.9 2023 Toyota Camry
©2023 VOXX•DEI LLC. All rights reserved.
Body ECU
Connector
1
2
2
1
3
9 8 7 6 5 4 3
18 17 16 15 14
RDA: Red,
pin 10
7 6 5 4 3 2 1
23 22 21 20 19
Cut
Ignition
Connector
(+) Ignition:
Lavender/Red,
pin 8
HS CAN High: HS CAN Low:
Tan, pin 5 White, pin 4
1
5 4 3 2
19 18 17 16 15 14 13 12 11 10 9 8
30 29 28 27 26 25 24 23 22
Body ECU
(middle conn. left side of steering column)
(-) Parking Light Output: Lt. Green/Black: 1
Siren
Hood Pin
Autolight Interrupt (conn. side): Blue/White: 1
TPMS Ignition Interrupt (veh. side): Lt. Green: 8
TPMS Ignition Interrupt (conn. side): Lt. Green/White: 9
(+) Starter:
Lavender/Violet,
pin 5
8 7 6 5 4 3 2 1
(+) Accessory:
Lt. Green, pin 6
White, pin 1
1
7 6
21 20
HS CAN Low 1: Tan: 1
HS CAN High 1: Tan/Black: 2
A
this installation.
RDA: Orange/Black: 7
SIL Data: Yellow/Black: 8
(-) GWA Output: Blue/White: 2
(+) Accessory Output: White: 7
(+) Ignition Output: Violet/Black: 8
(+) Siren Output: Brown/Red: 11
(+) Ignition Sense Input: Pink: 12
(-) Hood Input: Gray: 21
Autolight Interrupt (veh. side): Blue: 3
(+) Starter Output: White: 5 & 11
(+) 12V Input: Red: 6 & 12
(-) Ground: Black: 10
Dash Fuse Box
(white conn.)
3
1
(+) 12V:
).
module can also be used for
IMPORTANT:
Position the
fuses correctly!
Slide to open
Legend:
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
