Vehicle Connections - Directed DIRECTWIRE DIRECTECHS 933.TL14 Installation Manual

Vehicle connections

The connection information listed below is specific to the 2023 Toyota Camry. Refer to "Pre-installation and application warnings" for a list of important notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan (Data) HS CAN Low
H1/2 Tan/Black (Data) HS CAN High
H1/3 Orange/Brown (Data) HS CAN Low
H1/4 Orange/Green (Data) HS CAN High
H1/5 Lt. Green No Connection
H1/6 Violet/Brown No Connection
H1/7 Orange/Black (Data) RDA
H1/8 Yellow/Black (Data) SIL Data
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black (-) Pk Light Output
H2/2 Blue/White
(-) Ground When Armed (GWA) Output
H2/3 Dk. Green/Black (-) Lock Output
H2/4 Red/White (-) Trunk Output
H2/5 Brown/Black (-) Horn Output
H2/6 Brown/White (-) Accessory Output
H2/7 White (+) (+) Accessory Output
H2/8 Violet/Black (+) Ignition Output
H2/9 Dk. Blue/Black (-) Unlock Output
H2/10 Lt. Blue/Black (-) Key Wrap Output
H2/11 Brown/Red
(+) Siren Output
H2/12 Pink (+) Ignition Sense Input
H2/13 Violet No Connection
H2/14 Brown No Connection
H2/15 White/Blue No Connection
H2/16 Red/Blue No Connection
9 933.TL14 1.02.198.9 2023 Toyota Camry
©2023 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
Body ECU on dash fuse box, black 30 pin plug, pin 4
Body ECU on dash fuse box, black 30 pin plug, pin 5
No Connection
No Connection
No Connection
No Connection
Body ECU on dash fuse box, black 21 pin plug, pin 10
OBD-Data Link Connector, white 16 pin plug, pin 7
Connects To
Wire Location
Headlight Switch, white 40 pin plug, pin 3
[3] Starter:
Ignition Switch, white 8 pin plug, pin 5
Ignition:
Ignition Switch, white 8 pin plug, pin 8
Must use a relay.
Must use a 1A 1N4002 or larger diode.
No Connection
No Connection
Dash Fuse Box, white 32 pin plug (3C), pin 27
No Connection
Ignition Switch, white 8 pin plug, pin 6
Ignition Switch, white 8 pin plug, pin 8
No Connection
No Connection
[2] The siren is only required when enabling the security features during
module flashing.
Ignition Switch, white 8 pin plug, pin 8
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
Data White Mandatory
Data Tan Mandatory
Data Red Mandatory
Data Blue Remote Start
Only
(+/-) Wire Color Connection
- Green or Blue/Black Mandatory
+ Lavender/Violet Security Only
+ Lavender/Red
- White Optional
+ Lt. Green Remote Start
Only
+ Lavender/Red Remote Start
Only
Security Only
+ Lavender/Red Mandatory
