Remote Start Ribbon Harness; Heavy Gauge Relay Satellite; Relay Satellite 4-Pin Connector - Directed Electronics Python 533 Installation Manual

➤ Remote start ribbon harness

1 PINK/WHITE
2 YELLOW
3 PINK
4 ORANGE
5 PURPLE
6 ORANGE/BLACK
7 BLUE
The ribbon harness connects to the heavy gauge relay satellite.

➤ Heavy gauge relay satellite

H/1
PURPLE
H/2
GREEN
H/3
RED
H/4 ORANGE
H/5 PINK
H/6 RED
H/7 PINK/WHITE
H/8 RED/WHITE

➤ Relay satellite 4-pin connector

1 BLUE
2 ORANGE
3 PURPLE
4 PINK
14
(-) 200mA PROGRAMMABLE IGN2/ACC2 RELAY TURN ON
(+) IGNITION INPUT TO ALARM
(-) 200mA IGNITION RELAY TURN ON
(-) 200mA ACCESSORY RELAY TURN ON
(-) 200mA STARTER RELAY TURN ON
(-) 500mA ANTI GRIND/GROUND WHEN ARMED OUTPUT
(-) 200 mA STATUS OUTPUT
STARTER OUTPUT TO STARTER (STARTER SIDE)
STARTER INPUT FROM IGNITION (KEY SIDE)
(+) 30A HIGH CURRENT 12V INPUT
OUTPUT TO ACCESSORY CIRCUIT
OUTPUT TO PRIMARY IGNITION CIRCUIT
(+) (30A) HIGH CURRENT 12V INPUT
OUTPUT TO SECOND IGNITION CIRCUIT
(+) (30A) HIGH CURRENT 12V INPUT
(-) 200mA STATUS OUTPUT
(-) 200mA ACCESSORY RELAY TURN ON
(-) 200mA STARTER RELAY TURN ON
(-) 200mA IGNITION RELAY TURN ON
