Heavy Gauge Relay Satellite Wire Descriptions

RED (2) (+)12V Input for Relays
Remove the two 30 amp fuses prior to connecting these wires and do not replace them until the
satellite has been plugged into the control module. These wires are the source of current for all the
circuits the relay satellite will energize. They must be connected to a high current source. Since the
factory supplies (+) 12V to the key switch that is used to operate the motor, it is recommended that
these wires be connected there.
NOTE: If the factory supplies two separate (+) 12V feeds to the ignition switch, connect one RED
wire of the satellite to each feed at the switch.
PINK (+) Ignition Output
Connect this wire to the ignition wire in the vehicle.
ORANGE (+) Accessory Output
Connect this wire to the accessory wire in the vehicle that powers the climate control system.
PURPLE (+) Starter Output
Connect this wire to the starter wire in the vehicle.
PINK/WHITE (+) Output to Second Ignition Circuit
Connect this wire to the second ignition wire in the vehicle.
NOTE: For vehicles that do not have a second ignition wire, this connection is not required.

Remote Start Ribbon Harness Wiring Diagram

___
PURPLE
1
___
ORANGE
2
___
PINK
3
___
YELLOW
4
___
RED
5
© 2003
Directed Electronics, Inc.
(-) 200 mA Starter Relay Turn-On
(-) 200 mA Accessory Relay Turn-On
(-) 200 mA Ignition Relay Turn-On
(+) Ignition Input to Remote Start
(+) Constant Power
15
