door lock harness, 3-pin connector

______
1
______
2
______
3
Note: Refer to TechTip 1041 for wiring information.

remote start ribbon harness, wiring diagram

______
1
______
2
______
3
______
4
______
5
______
6
______
7
This ribbon harness connects to the relay satellite.
© 2006 Directed Electronics—all rights reserved
LIGHT BLUE
EMPTY
GREEN
PINK/WHITE 200 mA (-) PROGRAMMABLE IGN2/ACC2 RELAY TURN ON
YELLOW
PINK
ORANGE
PURPLE
ORANGE/BLACK
BLUE
(+) LOCK (-) UNLOCK OUTPUT
(-) LOCK (+) UNLOCK OUTPUT
(+) IGNITION INPUT TO ALARM
(-) 200 mA IGNITION RELAY TURN-ON
(-) 200 mA ACCESSORY RELAY TURN-ON
(-) 200 mA STARTER RELAY TURN-ON
(-) ANTIGRIND/GROUND WHEN ARMED OUTPUT
(-) 200 mA STATUS OUTPUT
NOT USED
