Directed Electronics Python 533 Installation Manual page 22

H2/3
VIOLET/BLACK
This wire provides 200 mA programmable output whenever the transmitter but-
tons controlling AUX 2 channel is pressed.
H2/4
GREEN/WHITE
This wire sends a negative 200mA pulse every time the remote start shuts down
or when the doors are locked. This can be used to pulse the arm wire of the
vehicle's factory anti-theft device. Use a relay to send a (-) or (+) pulse to the
arm wire.
H2/5 GRAY/BLACK
Connect this wire to the wire in the vehicle that sends the signal to turn on the
WAIT-TO-START bulb in the dashboard. In most diesels the wire is negative
(ground turns on the bulb) and the GRAY/BLACK wire can be directly connected
Sat mode,
to the wire in the vehicle. If the vehicle uses a positive wire (12V to turn on the
bank selector
bulb) a relay must be used to change the polarity.
Category
Note: A 1-amp diode must be installed in line on the factory wire between the
Control
wait-to-start indicator and the ECM. (See the following diagrams for details). The
system has a programmable onboard timer. It is not mandatory to connect to the
wait-to-start wire in the vehicle. (See menu #3 for programming details)
Toggles
Scan mode
22
(-) 200mA PROGRAMMABLE AUX 2 OUTPUT
Warning! Never use this wire to drive anything
but a relay or a low-current input, supplied
output is only 200mA. Connecting directly to
a solenoid, motor, or other high-current device
will cause the module to fail.
(-) 200mA FACTORY ALARM REARM OUTPUT
(-) DIESEL WAIT TO START BULB INPUT
Bank and
Tune mode
present
indicator
indicator
REW
1
11:53
CATEGORY CH
XM1-1 CH-001
FF PLAY/PROG
2 3
SCAN
VOL
AUDIO
© 2009 Directed Electronics. All rights reserved.
