Remote Start Ribbon Harness Wiring Diagram; Remote Start Harness (H3) Wiring Diagram - Directed Electronics Python 880XP Installation Manual

ORANGE (+) Accessory Output
Connect this wire to the accessory wire in the vehicle that powers the climate control system.
PURPLE (+) Starter Output
Connect this wire to the starter wire in the vehicle.
NOTE: If failsafe starter kill is installed, be sure the PURPLE wire is connected to the car side of
the failsafe starter kill relay.
PINK/WHITE (+) Output to Second Ignition Circuit
Connect this wire to the second ignition wire in the vehicle.
NOTE: For vehicles that do not have a second ignition wire, this connection is not required.

Remote Start Ribbon Harness Wiring Diagram

___
PURPLE
1
___
ORANGE
2
___
PINK
3
___
YELLOW
4
___
RED
5
Remote Start Harness (H3),
Wire Connection Guide

Remote Start Harness (H3) Wiring Diagram

___
BLUE
1
___
BLUE/BLACK
2
___
GRAY
3
___
BROWN
4
___
5 VIOLET/WHITE
___
6
BLACK/WHITE
© 2002
Directed Electronics, Inc.
(-) 200 mA Starter Relay Turn-On
(-) 200 mA Accessory Relay Turn-On
(-) 200 mA Ignition Relay Turn-On
(+) Ignition Input to Remote Start
(+) Constant Power
(-) Status/Factory Security Rearm Output
(-) 200 mA Optional Third Ignition Output
(-) Hood Pinswitch Shutdown Wire
(+) Brake Switch Shutdown Wire
Tachometer Input Wire
(-) Neutral Safety Switch Input
15
