Model 533
Installation Guide
This product is intended for installation by a professional
installer only! Attempts to install this product by a person other than a
trained professional may result in severe damage to a vehicle's electrical
system and components.
© 2009 Directed Electronics, Vista, CA
N5303P 2009-07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Python 533 and is the answer not in the manual?

Questions and answers

Related Manuals for Directed Electronics Python 533

Summary of Contents for Directed Electronics Python 533

  • Page 1 This product is intended for installation by a professional installer only! Attempts to install this product by a person other than a trained professional may result in severe damage to a vehicle’s electrical system and components. © 2009 Directed Electronics, Vista, CA N5303P 2009-07...
  • Page 2 Ghost Switch™, Learn Routine™, Nite-Lite®, Nuisance Prevention® Circuitry, Revenger®, Silent Mode™, Soft Chirp®, Stinger®, Valet®, Vehicle Recovery System®, VRS®, and Warn Away® are all Trademarks or Registered Trademarks of Directed Electronics. The Bitwriter® (p/n 998U) requires chip version 2.7 or newer to program this unit.

  • Page 3: Table Of Contents

    Contents Warning! Safety first ..................5 What is included ....................7 Installation points to remember ................8 Virtual tach ....................8 D2D ......................8 Before beginning the installation ..............9 After the installation ..................9 Component locations and finding wires ............10 Valet/program switch ................10 Status LED ....................11 Making your wiring connections ...............12 Primary harness (H1), 12-pin connector .............13 Auxiliary harness (H2), 6-pin connector .............13...
  • Page 4 Feature menus ....................42 Menu 1 - Basic ..................42 Menu 2 - Advanced ................43 Menu 3 - Remote start ................44 Feature descriptions ..................45 Menu 1 - Basic ..................45 Menu 2 - Advanced ................48 Menu 3 - Remote start ................51 Additional features ..................53 Table of zones ....................54 Long term event history ..................55 Shutdown diagnostics ..................56...

  • Page 5: Warning! Safety First

    This testing should be performed by an authorized Directed Electronics dealer in accordance with the Safety Check outlined in XM1-1 AUTO AUTO this product installation guide.
  • Page 6 The remote start module must be removed or properly reinstalled so that the vehicle does not start in gear. All installations must be performed by an authorized Directed Electronics dealer. OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION.

  • Page 7: What Is Included

    One 4-button 1-way transmitter (P/N 474P) • A Stinger™ DoubleGuard® two-stage shock sensor • A Revenger™ Soft Chirp™ six-tone programmable siren • A status LED indicator light • A push-button Valet® switch • A shut-down toggle switch © 2009 Directed Electronics. All rights reserved.

  • Page 8: Installation Points To Remember

    The advantage to using a D2D interface is that there is less wiring involved in the installation. Check the Xpresskit module installation guide to determine which wires are not needed, and which options are available. For more infor- mation visit www.xpresskit.com. © 2009 Directed Electronics. All rights reserved.

  • Page 9: Before Beginning The Installation

    Prevention® Circuitry (NPC). NPC can bypass trigger zones, making them appear to stop working. See the Nuisance Prevention® Circuitry section of the Owner's Guide. • Review and complete the Safety Check section of this guide prior to the vehicle reassembly. © 2009 Directed Electronics. All rights reserved.

  • Page 10: Component Locations And Finding Wires

    Valet/Program switch. This feature was introduced so that switch location was less critical in day-to-day use. As long as the Valet/Program switch can be reached to disarm without a transmitter, easy access is not im- portant. © 2009 Directed Electronics. All rights reserved.

  • Page 11: Status Led

    It is easiest to remove a small panel, such as a switch blank or a dash bezel, before drilling a 9/32-inch hole. • Use quick-disconnects near the LED wires if the panel is removable. This lets mechanics or other installers remove the panel without cutting the wires. © 2009 Directed Electronics. All rights reserved.

  • Page 12: Making Your Wiring Connections

    If you use tapping connectors such as T-Taps (not to be confused with Scotch- Locks), avoid using them in higher-current applications (constant 12V, ground, etc.) These connectors are inferior in quality and should be avoided. © 2009 Directed Electronics. All rights reserved.

  • Page 13: Primary Harness (H1), 12-Pin Connector

    (-) WAIT-TO-START INPUT H2/6 LIGHT GREEN/ (-) 200mA FACTORY ALARM DISARM OUTPUT BLACK ➤ Door lock harness, 3-pin connector LIGHT BLUE (-) UNLOCK (+) LOCK OUTPUT EMPTY NOT USED GREEN (-) LOCK (+) UNLOCK OUTPUT © 2009 Directed Electronics. All rights reserved.

  • Page 14: Remote Start Ribbon Harness

    (+) (30A) HIGH CURRENT 12V INPUT ➤ Relay satellite 4-pin connector BLUE (-) 200mA STATUS OUTPUT ORANGE (-) 200mA ACCESSORY RELAY TURN ON PURPLE (-) 200mA STARTER RELAY TURN ON PINK (-) 200mA IGNITION RELAY TURN ON © 2009 Directed Electronics. All rights reserved.

  • Page 15: Remote Start Harness, (H3) 5-Pin Connector

    Warning! Never use this wire to drive anything but a relay or a low-current input, supplied output is only 200mA. Connecting directly to a solenoid, motor, or other high-current device will cause the module to fail. © 2009 Directed Electronics. All rights reserved.
  • Page 16 Connect this to the red wire of the siren. Connect the black wire of the siren to (-) chassis ground, preferably at the same point you connected the control module’s black ground wire. © 2009 Directed Electronics. All rights reserved.
  • Page 17 This wire is used in vehicles that have a positive (+) switched dome light circuit. Connect the violet wire to a wire that shows (+)12V when any door is opened, and ground when the door is closed. This wire reports Zone 3. © 2009 Directed Electronics. All rights reserved.
  • Page 18 In vehicles with factory delays on the dome light circuit, there is usually a wire that is unaffected by the delay circuitry. This wire reports Zone 3. © 2009 Directed Electronics. All rights reserved.
  • Page 19 The number of activation inputs can be programmed to 1 or 2 pulses with an optional momentary switch. This setting affects both the input wire and the remote control when operating the remote starter. To white/blue activation input on system © 2009 Directed Electronics. All rights reserved.
  • Page 20 The output ceases as soon as the system is disarmed or when the remote start is de-activated. The orange wire may be wired to an optional Directed Electronics 8618 starter kill relay or to an optional accessory that requires a ground when armed to activate.

  • Page 21: Auxiliary Harness (H2), 6-Pin Connector

    Warning! Never use this wire to drive anything but a relay or a low-current input, supplied out- put is only 200mA. Connecting directly to a solenoid, motor, or other high-current device will cause the module to fail. © 2009 Directed Electronics. All rights reserved.
  • Page 22 It is not mandatory to connect to the wait-to-start wire in the vehicle. (See menu #3 for programming details) PLAY/PROG DISC- DISC+ Toggles Scan mode SOUND SCAN AUDIO © 2009 Directed Electronics. All rights reserved.
  • Page 23 (+)WAIT-TO-START WIRE © 2009 Directed Electronics. All rights reserved.

  • Page 24: Heavy Gauge Relay Satellite

    After cutting the starter wire connect the PURPLE wire to the end going to the starter motor. GREEN STARTER INPUT After cutting the starter wire connect the GREEN wire to the end going to the key side of the ignition. © 2009 Directed Electronics. All rights reserved.
  • Page 25 Connect this wire to a +12V source. It supplies voltage to the pink/white 2nd ignition/accessory output. If the vehicle does not have a 2nd ignition/acces- sory, then this wire does not need to be connected. © 2009 Directed Electronics. All rights reserved.

  • Page 26: Relay Satellite 4-Pin Connector

    In these vehicles, connect this wire to the toggle switch as shown in figure B. Connect the other wire from the toggle switch to chassis ground. © 2009 Directed Electronics. All rights reserved.
  • Page 27 This wire MUST be connected to a hoodpin switch. This input will disable or shut down the remote start when the hood is opened. It will also trigger the security system if the hood is opened while the system is armed and report Zone 6. © 2009 Directed Electronics. All rights reserved.

  • Page 28: Aux 4, Horn, (H4) 2-Pin Connector

    200mA. Connecting directly to a solenoid, motor, or other high-current device Bank and Channel Tune mode present and text will cause the module to fail. indicator indicator indicator Sat mode, bank selector 11:53 © 2009 Directed Electronics. All rights reserved. CATEGORY Category...

  • Page 29: Neutral Safety Switch Interface

    Motors product or a Dodge Dakota pickup, please call Directed Electron- ics Technical Support for an alternative shut-down method. Do not return the vehicle to the customer until this feature is properly installed! © 2009 Directed Electronics. All rights reserved.

  • Page 30: Plug-In Led And Valet/Program Switch

    Xpresskit module to the system. Once the Xpresskit module has been plugged in, reconnect the power to the alarm system and then reprogram the Xpresskit module. For more information visit www.xpresskit.com. © 2009 Directed Electronics. All rights reserved.

  • Page 31: Shock Sensor Harness, 4-Pin Connector

    Inputs shorter than 0.8 seconds will trigger the Warn Away® response, while inputs longer than 0.8 seconds will trigger full alarm sequence and report Zone 4. If installing an optional Directed Electronics dual stage sensor, connect to the green wire as shown below. When you use this connection it eliminates the need for diodes to isolate the sensors.

  • Page 32: Tachometer Settings

    Bitwriter to add or subtract the starter output time. You can adjust the output time in increments of 50mSec of the learned time using the Bitwriter. © 2009 Directed Electronics. All rights reserved.

  • Page 33: Tach Learning

    1. Start the vehicle with the key. 2. Within 5 seconds, press and hold the Valet/Program switch. 3. After 3 seconds the LED will light constant when the tach signal is learned. 4. Release the Valet/Program switch. © 2009 Directed Electronics. All rights reserved.

  • Page 34: Programming Jumpers

    For parking light circuits that draw 10 amps or more, the internal jumper must be switched to a (-) light flash output. P/N 8617 or a standard automotive SPDT relay must be used on the H1/11 light flash output harness wire. © 2009 Directed Electronics. All rights reserved.

  • Page 35: Transmitter/Receiver Learn Routine

    Once you have selected the function step, press the switch once more and hold it. The LED flashes and the siren chirps to confirm the selected functional step. Do not release the Program switch. © 2009 Directed Electronics. All rights reserved.
  • Page 36 5. Release. Once the code is learned, or the feature reset, the Valet/Program switch can be released. You can advance from programming one step to another by releasing the Valet/Program switch and tapping it to advance steps and then holding it. © 2009 Directed Electronics. All rights reserved.
  • Page 37 Learn Routine is exited if: • Door is closed. • The ignition is turned off. • The program switch is pressed too many times. • More than 15 seconds elapses between steps. © 2009 Directed Electronics. All rights reserved.

  • Page 38: Transmitter Configurations

    Disarm/Unlock Panic OFF operates Remote Start operates AUX Trunk Release operates Timer Mode operates Short Run/Turbo timer operates AUX 2 ������� ������� operates AUX 3 ������� Rear Defogger operates ������� operates AUX 4 © 2009 Directed Electronics. All rights reserved.

  • Page 39: Multi-Level Security Arming

    Zones Two and Four are now bypassed. ������� Press a fifth time within five seconds: The siren chirps five times followed by a long chirp. All input zones, except the ignition, are now bypassed. ������� ������� © 2009 Directed Electronics. All rights reserved.

  • Page 40: System Features Learn Routine

    Menu 1 has been selected. Continue to hold the switch until the LED flashes twice and the siren chirps twice; Menu 2 has now been selected. Release the switch after the Menu choice has been selected. © 2009 Directed Electronics. All rights reserved.
  • Page 41 The ignition is turned on. • The Valet/Program switch is pressed too many times. • More than 15 seconds elapses between programming steps. • Once long siren chirp indicates that the Learn routine has been exited. © 2009 Directed Electronics. All rights reserved.

  • Page 42: Feature Menus

    Horn Output Pulsed Constant Horn function Full Alarm Only (1) Siren function - chirp length 20mS (2), 30mS (3), 40mS (4), 50mS Comfort Closure ON (1) Comfort Closure OFF (2) Comfort Closure 2 (3) © 2009 Directed Electronics. All rights reserved.

  • Page 43: Menu 2 - Advanced

    AUX 4 validity (1) Latched (2), Latch reset with ignition ( 3 ) , 30-sec. timed (4)* Arm (2).Disarm (3), Remote Start (4) AUX 4 linking None (1) *Additional settings using the Bitwiter®. © 2009 Directed Electronics. All rights reserved.

  • Page 44: Menu 3 - Remote Start

    Timed 15 , 30 ,45 seconds* Timer mode run time: 12 min 3, 6, 9, min* Timer mode: Timed starts Temp starts Short run (turbo): 1 min 3,5, 10 min *Additional settings using the Bitwriter® © 2009 Directed Electronics. All rights reserved.

  • Page 45: Feature Descriptions

    Note: Remember, when passive arming is selected, the unit will chirp 20 sec- onds after the last door is closed. The system does not actually arm or lock the doors until 30 seconds after the door has been closed. © 2009 Directed Electronics. All rights reserved.
  • Page 46 1-10 ARMED WHILE DRIVING (AWD) ON/OFF: In the default setting (Armed While Driving), the system can be armed with the ignition on. When armed, the ground-when-armed is not active and the sensors are bypassed. The door triggers will remain active. © 2009 Directed Electronics. All rights reserved.
  • Page 47 Important: Comfort closure can only be used on cars that have the capability of closing the windows (and on some cars the sunroof as well) with the key cylinder in the door. © 2009 Directed Electronics. All rights reserved.

  • Page 48: Menu 2 - Advanced

    Ghost Switch option: For added security, the GRAY wire on the two-pin Valet/ Program plug can be connected to any switch in the vehicle that provides a positive (+) momentary pulse. © 2009 Directed Electronics. All rights reserved.
  • Page 49 Unlock is pressed. “Before Unlock” output to disarm the factory alarm activates before unlock and remote start are activated. The “Remote Start Only” output disarms the factory alarm before remote start is activated. © 2009 Directed Electronics. All rights reserved.
  • Page 50 To change the configuration, use the two-chirp setting to toggle through the different configurations. Refer to feature 2-12 for additional detail. 2-15 AUX 3 LINKING NONE(1)/ARM(2), DISARM(3), REMOTE START(4): Re- fer to feature 2-13 for additional detail. © 2009 Directed Electronics. All rights reserved.

  • Page 51: Menu 3 - Remote Start

    3-3 Parking Lights Constant: In the default setting, the parking lights (if con- nected) will come on solid during the remote start runtime. In the two- flash setting the parking lights will flash during the remote start runtime. © 2009 Directed Electronics. All rights reserved.
  • Page 52 “Wait-to-Start” input control wire, or programmable to ignore the input con- trol wire by a delay of 15, 30, or 45 seconds. This feature can also be pro- grammed with the Bitwriter® and with a delay from 1 to 90 seconds. © 2009 Directed Electronics. All rights reserved.

  • Page 53: Additional Features

    The factory default is 1 minute. Additional features For information on Nuisance Prevention Circuitry (NPC), Valet Mode, Rear Defogger control, Timer Mode and Owner Recognition, refer to the Owner's Guide at www.pythoncarsecurity.com. © 2009 Directed Electronics. All rights reserved.

  • Page 54: Table Of Zones

    Mux BLUE sensor port wire. Door Trigger GREEN (H1/8) and VIOLET (H1/6). Multiplexed Shock Sensor Input Mux GREEN wire Ignition Yellow ribbon harness wire Hood Trigger GRAY on the 6-pin shutdown har- ness © 2009 Directed Electronics. All rights reserved.

  • Page 55: Long Term Event History

    The LED will flash for one minute or until the ignition is turned off. NOTE: The Warning Zone triggers are not stored to memory and will not be reported. © 2009 Directed Electronics. All rights reserved.

  • Page 56: Shutdown Diagnostics

    Low or no RPM, low battery (for voltage and virtual tach modes) Transmitter shutdown (or optional push button) (-) Hood Shutdown (H3/4 GRAY) (+) Shutdown (H3/3 BROWN) (-) Neutral safety shutdown (H3/1 BLACK/WHITE) Wait-to-start timed out © 2009 Directed Electronics. All rights reserved.

  • Page 57: Safety Check

    If the starter does not engage, the test is complete. Once the system passes the tests, the vehicle can be re-assembled and delivered. Do not use the remote start system or finalize the installation if it fails any of the safety check tests. © 2009 Directed Electronics. All rights reserved.

  • Page 58: Troubleshooting

    Reducing the sensitivity can solve this problem. • The Valet/Program switch doesn't work. Is it plugged into the correct socket? See Plug-In LED and Valet/Program Switch section of this guide. © 2009 Directed Electronics. All rights reserved.

  • Page 59: Remote Start

    Check connections. The heavy gauge remote start input wires on the heavy gauge 10-pin connector should have a solid connection. “T-taps” or “scotch locks” are not recommended for any high current heavy gauge wiring. © 2009 Directed Electronics. All rights reserved.
  • Page 60 The climate control system does not work while the unit is operating the vehicle. Either the wrong accessory wire is being energized or more than one igni- tion or accessory wire must be energized in order to operate the climate control system. © 2009 Directed Electronics. All rights reserved.

  • Page 61: Wiring Quick Reference Guide

    Wiring quick reference guide © 2009 Directed Electronics. All rights reserved.

  • Page 62: Relay Satellite Wiring Quick Reference Guide

    Relay satellite wiring quick reference guide © 2009 Directed Electronics. All rights reserved.
  • Page 64 The company behind this system is Directed Electronics Since its inception, Directed Electronics has had one purpose, to provide con- sumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovation Awards in the field of advanced electronic technology.
