➤ Primary harness (H1), 12-pin connector

H1/1 RED/WHITE
H1/2 RED
H1/3 BROWN
H1/4 EMPTY
H1/5 BLACK
H1/6 VIOLET
H1/7 BLUE
H1/8 GREEN
H1/9 BLACK/WHITE
H1/10 WHITE/BLUE
H1/11
WHITE
H1/12
ORANGE

➤ Auxiliary harness (H2), 6-pin connector

H2/1
LIGHT BLUE
H2/2
WHITE/BLACK
H2/3
VIOLET/BLACK
H2/4
GREEN/WHITE
H2/5 GRAY/BLACK
H2/6 LIGHT GREEN/
BLACK

➤ Door lock harness, 3-pin connector

1 LIGHT BLUE
2 EMPTY
3 GREEN
© 2009 Directed Electronics. All rights reserved.
(-) 200mA AUX TRUNK RELEASE OUTPUT
(+) CONSTANT POWER INPUT
(+) SIREN OUTPUT
NOT USED
(-) CHASSIS GROUND INPUT
(+) DOOR TRIGGER INPUT, ZONE 3
(-) TRUNK PIN/INSTANT TRIGGER, ZONE 1
(-) DOOR TRIGGER INPUT, ZONE 3
(-) 200mA DOMELIGHT SUPERVISION OUTPUT
(-) REMOTE START ACTIVATION INPUT
(+)/(-) SELECTABLE LIGHT FLASH OUTPUT
(-) 500mA GROUND WHEN ARMED OUTPUT
(-) 200mA SECOND UNLOCK OUTPUT
(-) 200mA AUX 3 OUTPUT
(-) 200mA AUX 2 OUTPUT
(-) 200mA FACTORY ALARM REARM OUTPUT
(-) WAIT-TO-START INPUT
(-) 200mA FACTORY ALARM DISARM OUTPUT
(-) UNLOCK (+) LOCK OUTPUT
NOT USED
(-) LOCK (+) UNLOCK OUTPUT
