2-16 AUX 4 VALIDITY(1)/LATCHED(2)/LATCHED RESET WITH IGNI-
TION(3)/30, 60 and 90 SEC TIMED OUTPUT: AUX 3 can be programmed for
these output configurations. The unit is set to the default validity output. To change
the configuration, use the two-chirp setting to toggle through the different con-
figurations. Refer to feature 2-12 for additional detail.
2-17 AUX 4 LINKING NONE(1)/ARM(2), DISARM(3), REMOTE START(4): Re-
fer to feature 2-13 for additional detail.

➤ Menu 3 - Remote start

3-1 Engine Checking Virtual Tach:(1)
virtual tach the remote start monitors the cranking voltage of the vehicle and
sets it as a reference point. Fifteen seconds after the crank output sequence the
remote start checks the voltage again to determine if the vehicle is running.
When set to voltage the unit cranks the starter for the programmed time and then
attempts to sense that the engine is running by detecting an increase in voltage.
If programmed Off the vehicle cranks for the programmed crank time. The tach
setting or voltage setting is not checked to verify that the car is running. In the
OFF setting, if the vehicle fails to start, the ignition stays on for the run duration.
Using tach or either of the voltage settings is recommended.
When set to Tachometer the unit references the learned tach signal to disengage
the starter. In addition it will monitor the RPM and shut down if the engine RPM
is too high or too low.
3-2 RUN TIME 12, 24, 60 MINUTES: Selects the time in minutes that the
system will operate the engine until the system "times out". This is the maximum
operation period and the system may be shut down using a shutdown at any
time. Using the Bitwriter®, the run time can be programmed for any duration
from 1-60 minutes.
3-3 Parking Lights Constant: In the default setting, the parking lights (if con-
nected) will come on solid during the remote start runtime. In the two- flash setting
the parking lights will flash during the remote start runtime.
© 2009 Directed Electronics. All rights reserved.
Voltage(2)/Off(3)/Tach(4). When set to
