PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M8 Locknut M10 Locknut M6 Washer
(27)–2 (15)–9 (22)–1
M10 Washer
(16)–2
M4 x 19mm M6 x 16mm M6 x 55mm Screw (23)–1
M10 x 20mm
Screw (20)–1 Screw (21)–6
Bolt (28)–1
M8 x 55mm Bolt M10 x 60mm Bolt (25)–1
(19)–2
M10 x 65mm Carriage Bolt (14)–4 M10 x 70mm Bolt (17)–4
6
