PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled.
M8 Washer
M10 Curved
(55)–2
Washer (32)–1 M10 x 28mm
Washer (83)–2
M4 x 16mm
Screw (52)–8 M8 x 10mm M8 x 25mm
M8 Jam Nut M10 Locknut
Screw (27)–6 Screw (56)–2
(38)–8 (33)–1
M6 Bolt Set (25)–2 M8 x 41mm Bolt (50)–6
M8 x 77mm Bolt (79)–2 M10 x 20mm
Screw (40)–6
M10 x 68mm Screw (34)–4 M10 x 77mm Bolt (7)–1
