PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. Note: If a part is not in
the hardware kit, check to see whether it has been preassembled. Extra parts may be included.
M10 x 55mm Screw (21)–2
M6 Washer
(20)–6
M10 Washer
(17)–20
M6 x 70mm Screw (7)–2
M6 x 95mm Screw (8)–4
M10 x 95mm Bolt (18)–10
M10 Locknut
(16)–26
M10 x 70mm Bolt (19)–16
