PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M6 Locknut
(51)–4
M8 Split
M8 Small
Washer
(42)–8
#8 x 12mm
Screw (102)–4
M8 x 40mm Bolt (83)–6
M10 x 60mm Bolt (61)–1
M8 Locknut
(10)–10
Washer
M8 Large
(93)–4
Washer (54)–4
M4 x 16mm
Screw (47)–8
M8 x 125mm Bolt (58)–2
M10 x 25mm
Screw (96)–1
M10 Locknut M6 Curved
(48)–1
M10 Split
Washer (98)–2
M6 x 30mm M8 x 13mm
Bolt (49)–4 Screw (95)–6
M8 x 65mm Bolt (94)–2
M10 x 54mm Screw (97)–1
M10 x 65mm Screw (40)–4
6
Wave Washer
Washer (81)–4
(25)–4
M10 Curved
Washer (39)–3
M8 x 20mm
Screw (34)–4
