Chapter 2: Jumpers and Connectors

Connector Pin Definitions

External I/O Interfaces

Line-out Connector

Connector type: 1x 3.5mm TRS
Connector location: CN3
Pin Definition
1 LOUT_R
3 NC
5 GND
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 JD
4 LOUT_L
6 GND

Remote Power On/Off Switch

Connector type: 2-pin switch
Connector location: JP10
2 1
Pin Definition
1 PWRBT
2 GND
