Chapter 2: Jumpers and Connectors

Touch Sensor Connector

Connector type: 1x5 5-pin header JST, 2.5mm pitch
Connector location: J3
5
1
Pin
4-wire
1
Bottom
2
Right
3
N/A
4
Top
5
Left
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.

SATA Connector

Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180)
Connector location: CN8
1
5-wire
Pin
UR (H)
1
LR (X)
3
Sense (S)
5
UL (Y)
7
LL (L)
37
7
Definition
Pin
GND
2
TXN0
4
RXN0
6
GND
8
OPPC 1240T/1540T/1740T/1940T Series User Manual
Definition
TXP0
GND
RXP0
