Chapter 3: System Setup
OPPC 1740T Series
OPPC 1940T Series
366 ±0.5
403 ±0.5
7mm max.
CUT OUT SIZE T=7mm(MAX)
7mm max.
CUT OUT SIZE T=7mm(MAX)
3. Slide the Panel PC through the hole until it is properly fitted against the
panel.
71
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
OPPC 1240T/1540T/1740T/1940T Series User Manual
