Chapter 2: Jumpers and Connectors

Block Diagram

LVDS
48bit Support
@ Maximum resolution:1920 * 1080
0 - Internal connector
1- Internal/mini-PCIe
Connector
2 - MiniPCIE Connector
3G(USB)
3- Penmount Touch
Controller
MIC-IN
Line-in
HEAD PHONE
SPEAKER
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
CH7511
Display Port
DP to LVDS
VGA DB15Pin (Slim type)
VGA
Co-layout with BOX HEADER
@ Maximum resolution:1900 * 1200
USB 3.0
0 - Rear
USB 2.0X1
1-2 - Rear
USB 2.0X3
3- USB HUB 1~4
down stream
GENESYS GL850
SATA0 HDD
SATA Gen2
(DOM Support)
SATA1 CFAST
SATA Gen2
LPC Bus
Audio Codec
ALC886 80 port
AMP
TPS6047A4RHBR
DDI PORT0 DDI PORT1
DDR3L CH1
DDR3L CH2
Bay Trail-I
Dual Core CPU
E3826
DDR3L-1066
SPI 2MB
7W
3.25X27mm
PCIe x1
PCIe x1
PCIe x1
PCIe x1
HDA LCI LPC
Super I/O
ITE8786
Thermal Sensor *2
PS2 KB/MS
Voltages *4
46
DDR3L SO-DIMM
1 Slot
DDR3L SO-DIMM
2 Slot
@ Maximum 8GBytes
WOL Support
RJ45
LAN i210
Giga LAN
LAN i210 Giga LAN
RJ45
Mini-PCIe
Wi-Fi
Mini-PCIe
3G
GPIO2IN/2OUT
DIO BOX Header
COM1 RS-232/422/485 ISOLATION
COM2 RS-232/422/485 ISOLATION
COM3 RS-232
COM4 RS-232
