Chapter 3: System Setup
3. Secure the module with mounting screws.
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
4. Attach one end of the RF cables onto the module.
Mounting
screw
59
RF cable
OPPC 1240T/1540T/1740T/1940T Series User Manual
