Parts List - Flowserve FlowAct IG 253 Assembly Instructions Manual

Parts List

Item #
Part
WW EU
345 5.1 Valve Coupling
113 5.2 Lock Nut
1)
249 5.3 Actuator Coupling
344 5.4 Lock Nut
2)
240 5.5 Socket Head Screw
216 5.6 Stroke Indicator
213 5.7 Stroke Scale
2)
420 5.8 Hexagon Bolt
2)
201 5.9 Yoke
277 5.41 Gasket
1)
279 5.40 Screw Plug
1)
76 5.10 Valve Locknut
1)
256 5.11 Actuator Locknut
214 5.20 Socket Head Screw
202 6.1 Diaphragm Casing
203 6.2 Diaphragm Casing
335 6.3.1 Hexagon Bolt - short
336 6.3.2 Hexagon Bolt - long
351 6.4 Hexagon Nut
337 6.5 Plain Washer
209 6.6 Ring Nut
253 6.8.1 Guide Bush
3)
254 6.8.2 Plain Bearing
(ISO 3547-4)
275 6.10 O-Ring
273 6.11 Scraper Ring
211 6.12 Stem
228 6.13 Spacer Bush
227 6.15 Diaphragm Plate
225 6.16 Diaphragm
272 6.17 O-Ring
255 6.18 Thrust Washer
349 6.19 Lock Washer
348 6.20 Special Nut
229 6.21 Actuator Spring
231 6.22 Distance Plate
326 6.23 Spring Adjusting Plate
339 6.25 Protection Sleeve
258 6.26 Vent Plug
271 6.50 O-Ring
278 6.51 O-Ring
252 7.1 Serial Plate
4)
420 7.3 Warning Label
400 7.9 Brand-name Label
see page 21 see page 22
1) 2)
see page 9 see page 23
3) 4)
M = Diaphragm Kit
E = Gasket Kit
Spare
Mat.
Parts
A182
1)
A2-70
A182
2)
A2-70
A2-70
2)
SS
2)
SS
A2-70
A536
AFM 30
A2-70
1.4308
1.4308
A2-70
2)
1.0332
1.0332
A2-70
A2-70
A2-70
A2
C15
1.0736
P1
3)
NBR 70 E
NBR 90 E
A479
1.0308
1.0332
NBR 50 M
NBR 70 M
1.0736
C75 M
1.0736
1.7102
PA6
1.0330
VMQ
PA
NBR 70 E
NBR 70 E
SS
PP
4)
PP
4)
FlowAct IG - FCD VLENAI00IGA4 03/15
Figure xx: Complete actuator parts (left - spring close, right - spring opens)
258
209
335
337
336
337
203
348
349
231
255
272
326
225
229
227
348
349
228
227
211
229
225
272
255
326
211
202
351
339
258
275
273
271
278
256
201
www.flowserve-villach.com
43
