Step Image
6
7
Instruction
420
400
• Remove one hexagon bolt (336, 351) and install the
serial plate (252).
• Tighten the nut (336, 351). (See Page 13, Table A2)
252
• De-grease the adhesive surface and stick on the
warning label (420) and the brand-name label (400)
• The valve is ready for the mounting of the accessories.
• Refer to the relevant manufacturer's user instruction
for information regarding other ancillary equipment.
