Flowserve FlowAct IG 253 Assembly Instructions Manual page 28

Step Image
7
8
28
Instruction
420
• Remove one hexagon bolt (336, 351) and install the
400 serial plate (252).
252
• Tighten the nut (336, 351). (See Page 13, Table A2)
6.25
• De-grease the adhesive surface and stick on the
warning label (420) and the brand-name label (400)
• The valve is ready for the mounting of the accessories.
• Refer to the relevant manufacturer's user instruction
for information regarding other ancillary equipment.
FlowAct IG - FCD VLENAI00IGA4 03/15
