Step
3
4
30
Instruction
344
• Mount the lock nut (344) and actuator coupling (249)
onto the actuator stem.
249
• Justify the plug against the seat.
• Adjust the distance between the valve coupling (345)
and the actuator coupling (249) with the aid of an
adapter in stroke height.
Size
1/2" - 2"
FlowAct IG - FCD VLENAI00IGA4 03/15
Stroke
15 - 50
0.787
in.
+0.02
20
mm
+0.5
