PACSystems™ RXi Industrial Displays User Manual
GFK-3138E
WebPanel Settings
File System Build
Date
Authenticated user
Brightness
Date and Time
Password Settings
Home page
Network Setup
URL Page
Terminal
Display Orientation
Kiosk Mode Exit
RXi – Panel PC Overview
Icons Displayed
Description
Display the File System Build Date
Display the Authenticated user
Click on Brightness icon to adjust
the Brightness and configure Screen
standby interval timer
Click on Date and Time icon to set
the date and time.
Click on Password Settings icon to
set the user and root password
again.
Click on Home icon to Navigate to
Home page. Chromium browser
opens in Kiosk mode with the URL/IP
Address that the user has
configured on the first start up.
Click on Network icon to setup the
network.
Click on URL to input the url to
access the Web Page.
Click on terminal icon to open the
terminal
Click 270
, 180
, or 90
o
o
o
orientation of the webpanel. By
default,0
is set.
o
Click on Kiosk Mode Exit button to
exit the running Chromium Browser
from Kiosk Mode to normal Mode.
Section 4
Nov 2022
to change the
67
