PACSystems™ RXi Industrial Displays User Manual
GFK-3138E
3.6.14

Network Stack Configuration

This section is used to enable or disable network stack settings. The Network Stack Controls
LAN1 & LAN2 (Also LAN 3 & LAN4 on large computing module).
Figure 29: Network Stack Configuration
BIOS Parameter
Network Stack
Ipv4 PXE Support
Ipv6 PXE Support
PXE Boot Wait Time
Media Detect Time
RXi – Panel PC Overview
Description
Enable or disable the UEFI network stack. When
Network Stack is set to enabled, the screen will be
displayed as below.
When enabled, Ipv4 PXE boot supports. When disabled,
the Ipv4 PXE boot option will not be available.
When enabled, Ipv6 PXE boot supports. When disabled,
the Ipv6 PXE boot option will not be available.
Enter the wait time value to abort the PXE boot.
Enter the wait time in seconds to detect media.
Section 3
Nov 2022
30
