Rapid PN21-40 M2 Manual page 9

2. Release magazine by squeezing click lever. (Figure 4)
3. Loading brads: Hold the nail gun downwards and load
a strip of nails into the cartridge, with the points facing
downwards. (Figure 5) Push the rail until it clicks into
place. (Figure 6)
4. Use only recommended fasteners (see technical
specifi cations).
5. The tool and the fasteners specifi ed in the operating
instructions are to be considered as one unit safety
system.
TOOL USE
Keep tool pointed away from yourself and others
1.
and connect tool to air supply.
Tools shall be operated at the lowest pressure
2.
needed for the application. This will reduce noise
levels, part wear and energy use.
Press the nose of the tool onto the workpiece to
3.
be fastened and press the trigger to fi re staples.
(Figure 7)
Adjust the mini pressure which is necessary for
the penetration of the fasteners. Then, make some
tests in starting with the lowest pressure.
4. Check whether the fastener has been driven into the
workpiece in accordance with the requirements.
- if the fastener is protruding, increase the air pressure
in increments of 0,5 bar, checking the result after
each new adjustment;
- if the fastener is driven into an excessive depth,
reduce the air pressure in increments of 0,5 bar until
the result is satisfactory.
5. You should endeavour in any event to work with the
lowest possible air pressure.
6. Hold the tool during the work operation in such a
way that no injuries can be caused to the head or to
the body in the event of a possible recoil consequent
upon a disruption in the energy supply or hard areas
within the workpiece.
7. The tool shall be disconnected from the compressed
air system for the purpose of transportation, especially
where ladders are used or where an unusual physical
posture is adopted whilst moving.
8. Carry the fastener driving tool at the workplace using
only the handle, and never with the trigger actuated.
9. Take conditions at the workplace into account.
Fasteners can penetrate thin workpieces or slip
off corners and edges of workpieces, and thus put
people at risk.
10. For personal safety, use protective equipment such as
hearing and eye protection.
11. The trigger and the safety yoke have to be actuated for
each driving operation, with the order of actuation not
being specifi ed. For repeated driving operations, it is
suffi cient if either the trigger remains activated and the
safety yoke is activated thereafter, or vice versa.
12. Avoid triggering the tool if the magazine is empty.
13. Any defective or improperly functioning tool must
immediately be disconnected from the compressed air
supply and passed to a specialist for inspection.
14. In the event of longer breaks in work or at the end
of the working shift, disconnect the tool from the
compressed air supply and it is recommended to
empty the magazine.
15. The compressed air connectors of the tool and the
1. Proper functioning of the fastener driving tool requires
2. If the air pressure in the line system exceeds the
(Figure 1)
3. Connect the fastener driving tool to the compressed
4. The compressor plant shall be adequately
5. Permanently laid compressed air pipelines should
6. Compressed air pipelines should be laid so as to
7. Junctions for users should be joined to the pipelines
8. Connecting points for fastener driving tools should be
9. Oilers must be checked on a daily basis and if
1. If a pin jam occurs, disconnect tool from air
2. Release magazine and slide the rail back.
3. Or release the two screws of the front cover
MAINTENANCE:
1. While tool is disconnected from air supply, make daily
2. All screws should be kept tight. (Figure 2)
hoses should be protected against contamination. The
ingress of coarse dust, chips, sand etc. will result in
leaks and damage to the tool and the couplings.
COMPRESSED AIR SYSTEM
fi ltered, dry < and lubricated > compressed air in
adequate quantities. (Figure 11)
maximum allowable pressure of the fastener driving
tool, a pressure reducing valve followed by a
downstream safety valve shall additionally be fi tted in
the supply line to the tool.
air supply using suitable pressure hose equipped with
quick-action connectors. (Figure 1)
dimensioned in terms of pressure output and
performance (volumetric fl ow) for the consumption
which is to be expected. Line sections which are too
small in relation to the length of the line (pipes and
hoses), as well as overloading the compressor, will
result in pressure drops.
have an internal diameter of at least 19 mm and a
corresponding large diameter where relatively long
pipelines or multiple users are involved.
form a gradient (highest point in the direction to the
compressor). Easily accessible water separators
should be installed at the lowest points.
from above.
fi tted with a compressed air servicing unit (fi lter/water
separator/oiler) directly at the junction point.
necessary topped up with the recommended
grade of oil (see TECHNICAL DATA). Where hose
lengths of over 10 m are used, the oil supply for
the fastener driving tool cannot be guaranteed. We
therefore recommend that 2 to 5 drops (depending
on the loading of the fastener driving tool ) of the
recommended oil (see TECHNICAL DATA) should be
added via the air inlet of the tool, or an oiler attached
directly to the fastener driving tool.
TROUBLESHOOTING AND MAINTENANCE
supply.
(Figure 3)
Remove jammed fasteners.
(Figure 8)
and pull it out.
(Figure 9)
projectile. Replace the front cover
(Figure 10)
and tight the screws.
inspection to ensure free movement of safety yoke and
trigger.
Remove the jammed
