Parts List - Analog Devices SCP-LT8604C-BEVALZ Demo Manual

PARTS LIST

ITEM QTY REFERENCE
1 1 PCB
2 1 C1
3 1 C2
4 1 C3
5 1 C5
6 1 C6
7 1 C8
8 1 C9
9 1 INPUT
10 1 J1
11 1 L1
12 1 OUTPUT
13 1 P1
14 1 R1
15 10 R6, R7, R10, R11,
R12, R13, R19, R20,
R21, R22
16 3 R14, R15, R16
17 2 R17, R18
18 1 R2
19 1 R3
20 1 R4
21 1 R5
22 2 R8, R9
23 1 U1
24 1 VIOC
Note 1. These items are not stuffed (DNI).
Note 2. Keep R9 stuffed for output voltages of 3.3V to 25V.
DEMO MANUAL SCP-LT8604C-BEVALZ
PART DESCRIPTION
PCB
CAP ALUM ELECT 22uF 63V 20% 6.3X7.7mm
CAP CER 1uF 50V 10% X7R 1206
CAP CER 0.1uF 50V 10% X7R 0603
CAP CER 10pF 50V 5% C0G 0603
CAP CER 10uF 50V 20% X5R 1206
CAP CER 0.01uF 50V 10% X7R 0603
CAP CER 4.7uF 50V 10% X7R 1206
CONN-PCB MALE HEADER 3POS 2.54MM PITCH R/A GOLD
CONN-PCB STRAIGHT SMA PCB DIE CAST (Note 1)
IND SHIELDED POWER, 33uH 0.66OHM DCR 0.42A
CONN FEMALE 3POS 2.54MM PITCH R/A GOLD
CONN-PCB 3POS HEADER WIRE TO BRD WAFER ASSY
STRAIGHT 2MM PITCH (Note 1)
RES SMD 1MEG Ohm 5% 1/8W 0805
DO NOT INSTALL (Note 1)
RES SMD 0 Ohm 3/4W 0612
RES SMD 0 Ohm 3/4W 0612 (Note 1)
RES SMD 18.2K Ohm 1% 1/8W 0805
RES SMD 49.9K Ohm 1% 1/10W 0603
RES SMD 1MEG Ohm 1% 1/8W 0805
RES SMD 187K Ohm 1% 1/8W 0805
RES SMD 0 Ohm JUMPER 1/8W 0805 (Note 2)
IC-ADI HIGH EFFICIENCY 42V/120MA SYNCHRONOUS BUCK
CONN FEMALE 2POS 2.54MM PITCH R/A GOLD
MANUFACTURER/PART NUMBER
ANALOG DEVICES 08_065090a
UNITED CHEMI CON EMVE630ADA220MF80G
YAGEO CC1206KKX7R9BB105
SAMSUNG CL10B104KB8NNNC
SAMSUNG CL10C100JB8NNNC
SAMSUNG CL31A106MBHNNNE
YAGEO CC0603KRX7R9BB103
SAMSUNG CL31B475KBHNNNE
SULLINS PBC03SBAN
TE CONNECTIVITY LTD 5-1814832-2
WURTH ELEKTRONIK 744031330
SULLINS PPPC031LGBN-RC
MOLEX 53253-0370
YAGEO RC0805JR-071ML
TBD0805
VISHAY RCL06120000Z0EA
VISHAY RCL06120000Z0EA
PANASONIC ERJ-6ENF1822V
PANASONIC ERJ-3EKF4992V
PANASONIC ERJ-6ENF1004V
PANASONIC ERJ-6ENF1873V
VISHAY CRCW08050000Z0EA
ANALOG DEVICES LT8604CEV#TRPBF
SULLINS PPPC021LGBN-RC
Rev. 0
5
