MANAGED MODULES
The IE-iMcV-E1-Mux/4 modules are installed as a Host/Remote pair. Host or
Remote configuration is selected by an onboard DIP Switch setting. By
default, the DIP Switch setting is for a Host configuration. The Host/Remote
pair can be remotely managed when the HOST is installed in an
iMediaChassis with an SNMP Management Module.
PORT INTERFACES
A fully configured IE-iMcV-E1-Mux/4 includes the following ports:
•
Four E1 ports on RJ-48 connectors short haul
•
One 10/100BaseT twisted pair Ethernet port
•
One fiber SFP port (requires SFP/155-ED module for each port)
•
One SFP port for optical 1+1 protection.
•
One Mini Jack serial RS-232 serial console port
•
One user serial RS-232 data port (RJ-45)
The IE-iMcV-E1-Mux/4 is easily configured by using the serial console port
connection at the HOST side, view only at the remote end, or through an
SNMP management application such as iView².
NOTE: Some options require items that are sold separately, available from B+B SmartWorx.
iMcV-E1-Mux4, Ethernet Enhanced
7
