Advantech ITA-260 Series Startup Manual

ITA-260 Series Fanless Edge AI Compact Box with
Intel 11th Generation Processor
Startup Manual
Packing List
Before you begin installing your IPC, please make sure that
the following items have been shipped:
1. 1 x ITA-260 series IPC
2. 1 x Accessary box
3. 2 x Mounting brackets
4. 4 x Bottom rubber pads
5. 1 x Warranty card
6. 1 x DIN Rail for ITA-260
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note : Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the ITA-260 Series.
Part No. 2041A26000
Print in China
Specifications
Standard Functions
• Chip and chipset: Intel 11th Generation Processor
• BIOS: AMI SPI 64 MB Flash
• Memory: Flexible SO-DIMMs, up to 64GB with 2 slots
• Display: Intel
• Display mode
30H
• Storage: Supports 1 x M-Sata slot and 1 x 2.5" SSD
• Expansion slot:
- Support 2 x Mini PCIe & 1 x M.2 slots OR Support 2 x
M.2 & 1 x Mini PCIe slots
- Support 1 x nano SIM card slot
System Specifications
• Ethernet: 4 x RJ-45 & 2 x SFP or 6 x RJ-45
• USB: 2 x USB 2.0, 2 x USB 3.0
• DISPLAY: 1 x HDMI
• Serial port: 2 serial ports, with RS-232/422/485
• Digital I/O: 1 x 8bit GPIO (pin header)
Mechnical and Environment
• Dimensions (W x H x D):
- ITA-260V1-00A1/ITA-260V1-10A1: 70 x 150 x 120
mm(2.76" x 5.9" x 4.72")
- ITA-260V1-01A1/ITA-260V1-11A1: 100 x 150 x 120
mm(3.94" x 5.9" x 4.72" )
• Voltage input: DC 9 ~ 48 V input
• Working temperature:
• Humidity: 5 ~ 95%
note:
1.When the prototype is interfered by the pulse group, the flash screen phenomenon
may occur
2.The cables connected to the prototype network port are shielded network cables
1st Edition
August 2022
Iris Xe Graphics
® ®
: 1 x HDMI, up to 3840 x 21 60 @
-40 ~ 60° C (-40 ~ 140° F)
ITA-260 Startup Manual 1
