Advantech ITA-2230 Series Startup Manual

ITA-2230 Series Intel® Core™ i7 Fanless 2U
Rackmount System with 3 ITAM Slots
Startup Manual
Packing List
Before installing the board, please ensure that the following
items have been shipped:
1. 1 x ITA-2230 Series IPC
2. 1 x ITA-2230 Accessory Box
3. 1 x ITA-2230 Warranty Card
If any of the above items are missing or damaged, please
contact your distributor or sales representative immediately.
Note: Adobe Acrobat Reader is required to view PDF
files. Adobe Acrobat Reader can be downloaded at www.
adobe.com/Prodindex/acrobat/readstep2.html (Acrobat is a
trademark of Adobe).
Specifications
Standard Function
• Chip & Chipset: Intel Core™ i7-3555LE processor and
HM76 Chipset
• BIOS: AMI SPI 64 Mb
• Memory: Onboard DDR3 1600 up to 4GB
• Display:
Intel HD4000, Frequency 550MHz,
Share system memory up to 512MB SDRAM
• Dual display mode:
Resolution of single display up to 2048 x 1536,
1 x VGA, 1 x HDMI, 1 x eDP (Optional)
• Storage:
- 1 x 3.5"HDD or 2 x 2.5"HDD
- 1 x Full Size mSATA
• Expansion slot:
- 3 x ITAM slot
- 1 x PC104+
- 1 x Mini PCIe slot
For more information about this or other Advantech
products, please visit our website at
http://www.advantech.com
http://www.advantech.com/epc
For technical support and services, please visit our
support website at:
http://support.advantech.com
This manual is for the ITA-2230 Series.
Part No. 200K223010
Printed in China
1st Edition,
December 2014
Specifications (Cont.)
System Specifications
• Ethernet: 2 x 10/100/1000M Ethernet
• USB: 4 USB 3.0, 4 USB 2.0
• VGA: 1 VGA
• HDMI: 1 HDMI
• Serial port: 2 DB9 ports, support RS-232/422/485
• Digital I/O: 1 x 8-ch TTL GPIO
• Audio: 1 Speaker Out (support 2x4W Amp),1 Mic-in
• ITAM module (optional): ITAM modules can be optional
inserted into three ITAM slots to make LAN or COM ports
up to 24 additional ports for expansion needs.
Mechanical and Environment
• Dimensions (W x H x D): 483 x 88 x 325 mm
• Voltage input: AC 100-240 or DC 110V
• Working temperature:
- 0 -40° C (32 ~ 104° F , with HDD)
- 25 - 60° C (-13 ~ 140° F, with SSD)
• Weight:
- Single Power: 7.7 kg
- Dual Power: 8 kg
Jumpers and Connectors
Jumper/Connector Setting
The board has a number of jumpers and connectors that
allow you to configure your system to suit your application.
The table below lists the function of each of the jumpers
and connectors.
Name / Function
JCMOS1 Clear CMOS setting
PSON1 Power on mode setting
VCC_GPIO1 GPIO voltage setting
PC/104-Plus Connector VI/O
VIO1
Voltage setting
COM 1~2 Serial ports
HDMI HDMI connector
VGA 1 VGA connector
USB 1~2 USB3.0 connector
USB 3~6 USB2.0 connector
DIO Digital I/O
Audio Audio in
ITA-2230 Startup Manual 1
