ETHERNET BANDW IDTH CONTROL
This screen displays the settings for the end user to configure bandwidth in
32Kbps increments up to 100Mbps.

ETHERNET PORT STATUS SCREEN

This screen displays the current Ethernet port status for both the Host and
Remote site.
iMcV-E1-Mux4, Ethernet Enhanced
25
