CHARACTERISTICS:

The HD67611-A1 is a PROFINET / Modbus TCP Master Converter.
It allows for the following characteristics:
Up to 1440 bytes in reading and 1440 bytes in writing;
Isolation between Modbus/PROFINET - Power Supply;
Two-directional information between Modbus TCP bus and PROFINET bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67611 software on your PC in order to perform the following:
Define the parameters of PROFINET line;
Define the parameters of Modbus line;
Define the data to Read in Modbus and where to map these information in the PROFINET array;
Define the data to Write in Modbus and where to take the information in the PROFINET array;
Generate the XML file to be imported on the master PROFINET;
Update the device.
