Industrial Electronic Devices

User Manual

Revision 1.000

English

NMEA 0183 / Modbus Slave - Converter

(Order Code: HD67616-A1, HD67616-422-A1)

for Website information:

www.adfweb.com?Product=HD67616

for Price information:

www.adfweb.com?Price=HD67616-A1

www.adfweb.com?Price=HD67616-422-A1

Benefits and Main Features:

Very easy to configure

32mm Rail DIN mount

Wide supply input range

Temperature range: -40°C/+85°C (-40°F/+185°F)

User Manual

ADFweb.com Srl – IT31010 – Mareno – Treviso

User Manual NMEA 0183 / Modbus Slave - Converter

Document code: MN67616_ENG

For other Gateways / Bridges:

Serial / Modbus TCP - converter

Need help?

Do you have a question about the HD67616-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD67616-A1

Page 1 Revision 1.000 Page 1 of 30 Industrial Electronic Devices User Manual Revision 1.000 English NMEA 0183 / Modbus Slave - Converter (Order Code: HD67616-A1, HD67616-422-A1) for Website information: www.adfweb.com?Product=HD67616 for Price information: www.adfweb.com?Price=HD67616-A1 www.adfweb.com?Price=HD67616-422-A1 For other Gateways / Bridges: Benefits and Main Features:...
Page 2: Updated Documentation
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 2 of 30 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated...
Page 3: Security Alert
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 3 of 30 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation.
Page 4: Example Of Connection
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 4 of 30 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5: Connection Scheme
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 5 of 30 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67616-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 6 of 30 Industrial Electronic Devices Figure 1b: Connection scheme for HD67616-422-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 7 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 7 of 30 Industrial Electronic Devices CHARACTERISTICS: The “NMEA 0183 / Modbus Slave – Converter” allows the following characteristics: electrical isolation between NMEA 0183 – Modbus, Power Supply – Modbus, Power Supply – NMEA 0183; Multiple independent NMEA 0183 lines;...
Page 8: Power Supply
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 8 of 30 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. The consumption depends to the code of the device. For more details see the two tables below.
Page 9: Function Modes
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 9 of 30 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’...
Page 10 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 10 of 30 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
Page 11 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 11 of 30 Industrial Electronic Devices RS485: For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure. The maximum length of the cable should be 1200m (4000 feet).
Page 12 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 12 of 30 Industrial Electronic Devices RS422: For terminate the RS422 line with a 120Ω resistor it is necessary to put ON dip 1 for T line and/or put ON dip 2 for R line, like in figure. The maximum length of the cable should be 1200m (4000 feet).
Page 13 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 13 of 30 Industrial Electronic Devices RS232: The connection from RS232 socket to a serial port must be made with a Null Modem cable (a serial cable where the pins 2 and 3 are crossed).
Page 14 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 14 of 30 Industrial Electronic Devices ETHERNET: The Ethernet connection must be made using Connector5 of HD67616 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m.
Page 15 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 15 of 30 Industrial Electronic Devices USE OF COMPOSITOR SW67616: To configure the Converter, use the available software that runs with Windows called SW67616. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 16: New Configuration / Open Configuration
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 16 of 30 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “NMEA 0183 / Modbus Slave - Converter”...
Page 17: Software Options
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 17 of 30 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 18 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 18 of 30 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
Page 19: Set Communication
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 19 of 30 Industrial Electronic Devices SET COMMUNICATION: By Pressing the “Set Communication” button from the main window for SW67616 (Fig. 2) the window “Set Communication” appears (Fig. 3). The window is divided in different sections in order to define the different parameters of the converter: Modbus Slave...
Page 20 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 20 of 30 Industrial Electronic Devices ODBUS LAVE This section is used to define the main parameters of Modbus line. The means of the fields are: In the field “Serial”...
Page 21 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 21 of 30 Industrial Electronic Devices RS485: This section is used to define the main parameters of RS485 line. The means of the fields are: If the field “Enable RS485”...
Page 22: Receive Frames
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 22 of 30 Industrial Electronic Devices RECEIVE FRAMES: By pressing the “NMEA 0183 Access” button from the main window for SW67616 (Fig. 2) the “Definition of NMEA 0183 Sentences” window appears (Fig.
Page 23: Update Device
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 23 of 30 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. If you don’t know the actual IP address of the device you have to use this procedure: Turn OFF the Device;...
Page 24 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 24 of 30 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67616 device.
Page 25: Modbus Map
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 25 of 30 Industrial Electronic Devices MODBUS MAP: On Modbus side, the map is created automatically. In relation to the configuration defined, it is possible to have two different maps. Data in reading: Type Address...
Page 26: Mechanical Dimensions
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 26 of 30 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 7a: Mechanical dimensions scheme for HD67616-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 27 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 27 of 30 Industrial Electronic Devices Figure 7b: Mechanical dimensions scheme for HD67616-422-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 28: Ordering Informations
RS422: 1 x RS232, 1 x RS485, 1 x RS422 Device Family HD67616: NMEA 0183 / Modbus Slave - Converter Order Code: HD67616-A1 NMEA 0183 / Modbus Slave – Converter (1 x RS232, 2 x RS485) Order Code: HD67616-422-A1 NMEA 0183 / Modbus Slave – Converter (1 x RS232, 1 x RS485, 1 x RS422)
Page 29 User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 29 of 30 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 30: Warranties And Technical Support
User Manual NMEA 0183 / Modbus Slave - Converter Document code: MN67616_ENG Revision 1.000 Page 30 of 30 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
