Industrial Electronic Devices
User Manual
Revision 1.000
English
S7comm / SNMP Agent - Converter
(Order Code: HD67626-A1)
for Website information:
http://www.adfweb.com/?Product=HD67626
for Price information:
http://www.adfweb.com/?Price=HD67626-A1
Benefits and Main Features:
Triple electrical isolation
Two Ethernet ports
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual S7comm / SNMP Agent
Document code: MN67626_ENG
Revision 1.000
For others S7comm devices, see also the following links:
S7comm from/to ...
www.adfweb.com?Product=HD67618
www.adfweb.com?Product=HD67619
www.adfweb.com?Product=HD67620
www.adfweb.com?Product=HD67621
www.adfweb.com?Product=HD67622
www.adfweb.com?Product=HD67623
www.adfweb.com?Product=HD67624
www.adfweb.com?Product=HD67625
www.adfweb.com?Product=HD67627
www.adfweb.com?Product=HD67628
www.adfweb.com?Product=HD67629
www.adfweb.com?Product=HD67630
www.adfweb.com?Product=HD67631
www.adfweb.com?Product=HD67632
www.adfweb.com?Product=HD67633
www.adfweb.com?Product=HD67D39
www.adfweb.com?Product=HD67E28
Do you have an your customer protocol?
See the following links:
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Page 1 of 27
(Modbus TCP Slave)
(PROFIBUS Slave)
(IEC61850 Server)
(Serial)
(Modbus Slave)
(CAN)
(CANopen)
(DeviceNet Slave)
(EtherNet/IP Slave)
(KNX)
(MQTT)
(BACnet Slave)
(Ethernet)
(OPC UA Server)
(PROFINET Slave)
(LoRaWAN)
(S7comm)
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Related Manuals for ADF Web HD67626-A1
Summary of Contents for ADF Web HD67626-A1
- Page 1 Page 1 of 27 Industrial Electronic Devices User Manual Revision 1.000 English S7comm / SNMP Agent - Converter (Order Code: HD67626-A1) for Website information: http://www.adfweb.com/?Product=HD67626 For others S7comm devices, see also the following links: for Price information: http://www.adfweb.com/?Price=HD67626-A1 S7comm from/to …...
-
Page 2: Table Of Contents
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 2 of 27 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated... -
Page 3: Security Alert
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 3 of 27 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 4 of 27 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 5 of 27 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67626-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 6: Characteristics
Revision 1.000 Page 6 of 27 Industrial Electronic Devices CHARACTERISTICS: The HD67626-A1 is a S7comm / SNMP Agent Converter. It allows the following characteristics: Two-directional information between S7comm and SNMP; Mountable on 35mm Rail DIN; Wide power supply input range: 8…24V AC or 12…35V DC;... -
Page 7: Power Supply
POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax Vmin Vmax HD67626-A1 Consumption at 24V DC: Device W/VA HD67626-A1 Caution: Not reverse the polarity power HD67626-A1 ADFweb.com Srl –... -
Page 8: Function Modes
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 8 of 27 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’: The first, with Dip1 in Off position (factory setting), is used for the normal working of the device. The second, with Dip1 in On position, is used for upload the Project/Firmware. -
Page 9: Leds
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 9 of 27 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode ON: Device powered... -
Page 10: Ethernet
ETHERNET: The Ethernet connection must be made using Connector3 or Connector4 of HD67626-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable. -
Page 11: Use Of Compositor Sw67626
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 11 of 27 Industrial Electronic Devices USE OF COMPOSITOR SW67626: To configure the Converter, use the available software that runs with Windows called SW67626. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 12: New Project / Open Project
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 12 of 27 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “S7comm / SNMP Agent - Converter”... -
Page 13: Software Options
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 13 of 27 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 14 User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 14 of 27 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 15: Set Communication
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 15 of 27 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, SNMP and S7comm. By Pressing the “Set Communication” button from the main window for SW67626 (Fig. 2) the window “Set Communication”... - Page 16 User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 16 of 27 Industrial Electronic Devices In the field "Location" the location for SNMP Agent station is defined; In the field “Version” the version of SNMP is defined; If SNMP V3 is used, the following fields must be filled: In the field “User”...
-
Page 17: S7Comm Access
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 17 of 27 Industrial Electronic Devices S7comm ACCESS: By Pressing the “S7comm Access ” button from the main window of SW67626 (Fig. 2), the window “Set S7comm Access” appears (Fig. 4). The window is divided in two parts, the “S7comm Read”... - Page 18 User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 18 of 27 Industrial Electronic Devices In the field “Start Bit” is used for the “Bit” data. It is possible to select the bit of the selected Position where mapping the data; If the field “Swap”...
- Page 19 User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 19 of 27 Industrial Electronic Devices Figure 4b: “S7 Protocol Access S7comm Write” window The means of the fields in the window “S7comm Read” are the following: In the field “PLC Address”...
-
Page 20: Set Snmp Access
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 20 of 27 Industrial Electronic Devices SET SNMP ACCESS: By pressing the “Set SNMP Access” button from the main window for SW67626 (Fig. 2) the “Set SNMP Access” window appears (Fig. 5). In this section, it is possible to create the OIDs for SNMP side to read or write using GET and SET commands or to be sent as TRAP messages. -
Page 21: Mib File
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 21 of 27 Industrial Electronic Devices The data of the columns in the “SNMP Write” have the following meanings: field “Enable” checked, the SNMP OID is enabled; field “Community Name”... -
Page 22: Update Device
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 22 of 27 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. - Page 23 User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 23 of 27 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67626 device. Warning: If Fig.
-
Page 24: Mechanical Dimensions
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 24 of 27 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67626-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 25: Ordering Informations
Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67626: S7comm / SNMP Agent - Converter Order Code: HD67626-A1 S7comm / SNMP Agent - Converter ACCESSORIES: Order Code: AC34011 Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V DC Order Code: AC34012 Rail DIN - Power Supply 220/240V AC 50/60Hz –... -
Page 26: Disclaimer
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 26 of 27 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 27: Warranties And Technical Support
User Manual S7comm / SNMP Agent Document code: MN67626_ENG Revision 1.000 Page 27 of 27 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
