Industrial Electronic Devices

User Manual

Revision 1.001

English

PROFINET / NMEA 0183 - Converter

(Order Code: HD67615-A1, HD67615-422-A1)

for Website information:

www.adfweb.com?Product=HD67615

for Price information:

www.adfweb.com?Price=HD67615-A1

www.adfweb.com?Price=HD67615-422-A1

Benefits and Main Features:

Very easy to configure

32mm Rail DIN mount

Wide supply input range

Temperature range: -40°C/+85°C (-40°F/+185°F)

User Manual

ADFweb.com Srl – IT31010 – Mareno – Treviso

User Manual PROFINET / NMEA 0183 - Converter

Document code: MN67615_ENG

Revision 1.001

For other Gateways / Bridges:

Serial / Modbus TCP - converter

Need help?

Do you have a question about the HD67615-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD67615-A1

Page 1 Revision 1.001 Page 1 of 29 Industrial Electronic Devices User Manual Revision 1.001 English PROFINET / NMEA 0183 - Converter (Order Code: HD67615-A1, HD67615-422-A1) for Website information: www.adfweb.com?Product=HD67615 for Price information: www.adfweb.com?Price=HD67615-A1 www.adfweb.com?Price=HD67615-422-A1 Benefits and Main Features: For other Gateways / Bridges:...
Page 2: Updated Documentation
User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 2 of 29 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated...
Page 3: Security Alert
User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 3 of 29 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation.
Page 4: Example Of Connection
User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 4 of 29 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5: Connection Scheme
User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 5 of 29 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67615-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 6 of 29 Industrial Electronic Devices Figure 1b: Connection scheme for HD67615-422-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 7 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 7 of 29 Industrial Electronic Devices CHARACTERISTICS: The “PROFINET / NMEA 0183 – Converter” allows the following characteristics: electrical isolation between NMEA 0183 – PROFINET, Power Supply – PROFINET, Power Supply – NMEA 0183; Multiple independent NMEA 0183 lines;...
Page 8: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. The consumption depends to the code of the device. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67615-xxx-A1 Caution: Not reverse the polarity power HD67615-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 9: Function Modes
User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 9 of 29 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’...
Page 10 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 10 of 29 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
Page 11 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 11 of 29 Industrial Electronic Devices RS485: For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure. The maximum length of the cable should be 1200m (4000 feet).
Page 12 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 12 of 29 Industrial Electronic Devices RS422: For terminating the RS422 line with a 120Ω resistor it is necessary to put ON dip 1 for T line and/or put ON dip 2 for R line, like in figure. The maximum length of the cable should be 1200m (4000 feet).
Page 13 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 13 of 29 Industrial Electronic Devices RS232: The connection from RS232 socket to a serial port must be made with a Null Modem cable (a serial cable where the pins 2 and 3 are crossed). It is recommended that the RS232 cable not exceed 15 meters.
Page 14 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 14 of 29 Industrial Electronic Devices ETHERNET: The Ethernet connection must be made using Connector5 of HD67615 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m.
Page 15 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 15 of 29 Industrial Electronic Devices USE OF COMPOSITOR SW67615: To configure the Converter, use the available software that runs with Windows called SW67615. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 16: New Configuration / Open Configuration
User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 16 of 29 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “PROFINET / NMEA 0183 - Converter”...
Page 17: Software Options
User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 17 of 29 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 18 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 18 of 29 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
Page 19: Set Communication
User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 19 of 29 Industrial Electronic Devices SET COMMUNICATION: By Pressing the “Set Communication” button from the main window for SW67615 (Fig. 2) the window “Set Communication” appears (Fig. 3). The window is divided in different sections in order to define the different parameters of the converter: PROFINET...
Page 20 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 20 of 29 Industrial Electronic Devices PROFINET: This section is used to define the parameters of PROFINET side of the converter. It is possible to define: In the field “IP Address”...
Page 21 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 21 of 29 Industrial Electronic Devices RS485 2: This section is used to define the main parameters of RS485 2 line. The means of the fields are: If the field “Enable RS485 2”...
Page 22: Receive Frames
User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 22 of 29 Industrial Electronic Devices RECEIVE FRAMES: By pressing the “NMEA 0183 Access” button from the main window for SW67615 (Fig. 2) the “Definition of NMEA 0183 Sentences” window appears (Fig.
Page 23 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 23 of 29 Industrial Electronic Devices PROFINET XML: By Pressing the “PROFINET XML” button from the main window for SW67615 (Fig. 2) it is possible to generate the xml file to be imported into the master PROFINET.
Page 24: Update Device
User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 24 of 29 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. If you don’t know the actual IP address of the device you have to use this procedure: Turn OFF the Device;...
Page 25 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 25 of 29 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67615 device.
Page 26: Mechanical Dimensions
User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 26 of 29 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67615-xxx-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 27: Ordering Informations
RS422: 1 x RS232, 1 x RS485, 1 x RS422 Device Family HD67615: PROFINET / NMEA 0183 - Converter Order Code: HD67615-A1 PROFINET / NMEA 0183 – Converter (1 x RS232, 2 x RS485) Order Code: HD67615-422-A1 PROFINET / NMEA 0183 – Converter (1 x RS232, 1 x RS485, 1 x RS422)
Page 28 User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 28 of 29 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 29: Warranties And Technical Support
User Manual PROFINET / NMEA 0183 - Converter Document code: MN67615_ENG Revision 1.001 Page 29 of 29 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
