Industrial Electronic Devices
User Manual
Revision 1.001
English
PROFINET / Modbus TCP Master - Converter
(Order Code: HD67611-A1)
For Website information:
www.adfweb.com?Product=HD67611
For Price information:
www.adfweb.com?Price=HD67611-A1
Benefits and Main Features:
Very easy to configure
Electrical isolation
Two Ethernet ports (for Modbus TCP / PROFINET)
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
Axis Solutions Pvt Ltd is the Authorized Distributor of
Axis Solutions Pvt Ltd is the Authorized Distributor of
Axis Solutions Pvt Ltd is the Authorized Distributor of
Axis Solutions Pvt Ltd is the Authorized Distributor of
www.axisindia.in | info@axisindia.in
www.axisindia.in | info@axisindia.in
www.axisindia.in | info@axisindia.in
www.axisindia.in | info@axisindia.in
User Manual PROFINET / Modbus TCP Master
Document code: MN67611_ENG
For other PROFINET products see also the following link:
Converter PROFINET to
www.adfweb.com?Product=HD67608
www.adfweb.com?Product=HD67609
www.adfweb.com?Product=HD67610
www.adfweb.com?Product=HD67600
www.adfweb.com?Product=HD67602
www.adfweb.com?Product=HD67602
www.adfweb.com?Product=HD67603
www.adfweb.com?Product=HD67631
www.adfweb.com?Product=HD67604
www.adfweb.com?Product=HD67605
www.adfweb.com?Product=HD67606
Do you have your customer protocol? Then go to:
www.adfweb.com?Product=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
in India
in India
in India
in India
Revision 1.001
Page 1 of 29
(DeviceNet Master)
(DeviceNet Slave)
(J1939)
(NMEA2000)
(Modbus Master RS232)
(Modbus Master RS485)
(Modbus Slave RS232)
(Modbus Slave RS485)
(PROFIBUS Master)
(PROFIBUS Slave)
(CAN)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADF Web AXIS HD67611-A1
Summary of Contents for ADF Web AXIS HD67611-A1
- Page 1 User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 1 of 29 Industrial Electronic Devices User Manual Revision 1.001 English PROFINET / Modbus TCP Master - Converter (Order Code: HD67611-A1) For Website information: www.adfweb.com?Product=HD67611 For Price information: www.adfweb.com?Price=HD67611-A1 Benefits and Main Features: Very easy to configure...
-
Page 2: Table Of Contents
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 2 of 29 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that INDEX you need to check that the following document is: UPDATED DOCUMENTATION Updated REVISION LIST... -
Page 3: Security Alert
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 3 of 29 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 4 of 29 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 5 of 29 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67611-A1 ADFweb.com S.r.l. -
Page 6: Characteristics
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 6 of 29 Industrial Electronic Devices CHARACTERISTICS: The HD67611-A1 is a PROFINET / Modbus TCP Master Converter. It allows for the following characteristics: Up to 1440 bytes in reading and 1440 bytes in writing; Isolation between Modbus/PROFINET - Power Supply;... -
Page 7: Power Supply
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 7 of 29 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin... -
Page 8: Function Modes
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 8 of 29 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’... -
Page 9: Leds
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 9 of 29 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information about the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode ON: Device powered... -
Page 10: Profinet / Modbus Tcp
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 10 of 29 Industrial Electronic Devices PROFINET / MODBUS TCP: The PROFINET and Modbus TCP connection must be made using Connector3 and/or Connector4 of HD67611-A1 with at least a Category 5E cable. -
Page 11: Use Of Compositor Sw67611
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 11 of 29 Industrial Electronic Devices USE OF COMPOSITOR SW67611: To configure the Converter, use the available software that runs with Windows called SW67611. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 12: New Project / Open Project
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 12 of 29 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “PROFINET Slave / Modbus TCP Master - Converter”... -
Page 13: Software Options
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 13 of 29 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. -
Page 14: Set Communication
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 14 of 29 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, PROFINET and Modbus. By Pressing the “Set Communication” button from the main window for SW67611 (Fig. 2) the window “Set Communication”... - Page 15 User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 15 of 29 Industrial Electronic Devices The means of the fields for the “Modbus TCP Master” section are: In the fields “IP ADDRESS” insert the IP address that you want to give to the Converter (Modbus TCP side); In the fields “SUBNET Mask”...
-
Page 16: Set Modbus Access
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 16 of 29 Industrial Electronic Devices SET MODBUS ACCESS: By Pressing the “Set Modbus Access ” button from the main window for SW67611 (Fig. 2) the window “Set Access” appears (Fig. 4). The window is divided in two parts, the “Modbus Read”... -
Page 17: Xml File
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 17 of 29 Industrial Electronic Devices In the field “Max Error” insert the number of consecutive errors that the Master waits before discard the row from the cycle of requests;... -
Page 18: Update Device
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 18 of 29 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button it is possible to load the created Configuration into the device; and also the Firmware, if is necessary. - Page 19 User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 19 of 29 Industrial Electronic Devices If you know the actual IP address of the device you have to use this procedure: Turn on the Device with the Ethernet cable inserted; Insert the actual IP of the Converter;...
-
Page 20: Modbus Diagnostic Over Profinet
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 20 of 29 Industrial Electronic Devices MODBUS DIAGNOSTIC OVER PROFINET: During the normal functioning of the device, if all the programmed Modbus requests have received a valid reply (not an exception error), every PROFINET frame has the "Data Status"... -
Page 21: Mechanical Dimensions
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 21 of 29 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67611-A1 ADFweb.com S.r.l. -
Page 22: Ordering Informations
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 22 of 29 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67611 – A 1 Connectors Type 1: Removable 5mm Screw Terminal Enclosure Type A: 1M, 35mm DIN Rail mounting... -
Page 23: Plc Configuration
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 23 of 29 Industrial Electronic Devices PLC CONFIGURATION: The configuration and commissioning of the PROFINET Converter as described on the following pages was accomplished with the help of the TIA Portal V11-software by Siemens. - Page 24 User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 24 of 29 Industrial Electronic Devices 2) Press the “Devices and networks” button (1), from the right drop-down menu, under “Other field devices PROFINET IO Gateway ADFWEB.com HD67611” double click on “modbus” module (2). Note: If you have installed more than one GSD file, go to the Information section and in the “Version”...
- Page 25 User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 25 of 29 Industrial Electronic Devices 3) Connect the PLC to the HD67611 module by drawing the Ethernet wire between the two Ethernet ports. Then assign the IP Address defined in the Compositor_SW67611 to the HD67611-A1.
- Page 26 User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 26 of 29 Industrial Electronic Devices 4) Then double click on the “Serial” label and in the field name change it accordingly to the name defined in the Compositor_SW67611 (2).
- Page 27 User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 27 of 29 Industrial Electronic Devices 5) Load the configuration into the PLC. ADFweb.com S.r.l.
-
Page 28: Disclaimer
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 28 of 29 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 29: Warranties And Technical Support
User Manual PROFINET / Modbus TCP Master Document code: MN67611_ENG Revision 1.001 Page 29 of 29 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
