ORDERING INFORMATION

BILL OF MATERIALS

Table 4.
Qty Name Description
4 IC AD8021ARZ
23 Capacitor 0.1 μF, 16 V, 0603, X7R
2 Capacitor 22 pF, 50 V, 5%, 0603
2 Capacitor 10 μF, 10 V, A size tantalum
4 Capacitor 2.2 nF, 50 V, X7R, 10%, 0603
4 Capacitor 5 pF, 50 V, 0603
2 Capacitor 0.018 μF, 10%, 50 V, X7R, 0603
1 Capacitor 1 nF, 100 V, 10%, 0603, X7R
1 IC AD8333 I/Q demodulator
7 Connector SMA female PC mount, RA
7 Ferrite Bead 120 nH, 0603
1 Resistor 100 Ω, 1%, 1/16 W, 0603
6 Resistor 0 Ω, 5%, 1/10 W, 0603
1 Resistor 3.48 kΩ, 1%, 1/10 W, 0603
1 Resistor 1.5 kΩ, 1%, 1/10 W, 0603
2 Resistor 274 Ω, 1/16 W, 1%, 0603
1 Resistor 49.9 Ω, 1%, 1/16 W, 0603
4 Resistor 20 Ω, 1%, 1/10 W, 0603
4 Resistor 787 Ω, 1/16 W, 1%, 0603
10 Header 3-pin 0.025" sq., 0.1" spacing
1 Test Loop 0.125" diameter, red
4 Test Loop 0.125" diameter, black
1 Test Loop 0.125" diameter, blue
5 Test Loop 0.125" diameter, purple
1 IC VGA AD8332
1 IC DRV LVDS dual differential
signal 8-lead SOIC
1 PC Board
4 Bumper
10 Jumper
Reference Designator
A1 to A4
C1, C4, C5, C6, C9, C11, C12, C13,
C14, C17, C24, C36, C41, C42,
C44, C45, C46, C47, C48, C49,
C50, C51, C52
C2, C3
C7, C8
C26, C29, C31, C32
C27, C28, C30, C33
C39, C40
C43
DUT
I1, I2, IN1, IN2, LOP, Q1, Q2
L1, L2, L3, L4, L5, L6, L7
R1
R2, R3, R32, R33, R35, R38
R6
R7
R9, R10
R13
R22, R23, R25, R26
R39 to R42
ENBL, PH10, PH11, PH12, PH13,
PH20, PH21, PH22, PH23, RST
+5 V
GND1 to GND4
−5 V
TP5 to TP8, RST
Z1
Z3
Mount to wiring side of board
Install at ENBL: top, PH10: top,
PH11: top, PH12: top, PH13: top,
PH20: bottom, PH21: bottom,
PH22: bottom, PH23: bottom,
RST: right; orient when board is in
normal viewing position with IN1
and IN2 SMA connectors at left
Rev. B | Page 9 of 12
AD8333-EVALZ
Mfg. Part Number Manufacturer
AD8021ARZ Analog Devices, Inc.
C0603C104K4RACTU KEMET Corporation
ECJ-1VC1H220J Panasonic
T491A106M010AS KEMET Corporation
ECJ-1VB1H222K Panasonic
ECJ-1VC1H050C Panasonic
06035C183KAT2A AVX Corp.
ECJ-1VB2A102K Panasonic
AD8333ACPZ-WP Analog Devices, Inc.
901-143-6RFX Amphenol
BLM18BA750SN1D Murata Manufacturing Co.
ERJ-3EKF1000V Panasonic
ERJ-2GE0R00X Panasonic
ERJ-3EKF3.48KV Panasonic
ERJ3EKF1501V Panasonic
ERJ-3EKF2740V Panasonic
ERJ-3EKF49R9V Panasonic
ERJ3EKF20R0V Panasonic
ERJ-3EKF7870V Panasonic
22-11-2032 Molex, Inc.
TP-104-01-02 Components Corp.
TP-104-01-00 Components Corp.
TP-104-01-06P Components Corp.
TP-104-01-07 Components Corp.
AD8332ACPZ Analog Devices, Inc.
DS90C401M National Semiconductor
09-A00941C
SJ-67A11 (black) 3M
65474-001 FCI
