Ensure a minimum distance to other objects and surfaces as shown in
Fig. 5.1 to guarantee sufficient heat dissipation and to have enough space
for removing wires.
•
Install in a room where noise is not an issue as the unit has
fans for cooling. Under maximum load, the fan noise
typically does not exceed 60 dBa. Under no load, but with
the AC output turned on, the minimum noise is
approximately 35 dBa, as the fans rotate at about 30% of
their maximum speed.The fans are speed-controlled
according to current PV and inverter power. Air is taken in
from the top vents and expelled toward the bottom.
Install the unit by using four (PSW-H-5KW-120/48V, PSW-H-6.5KW-
120/48V and PSW-H-8KW-230/48V) or three (all other models) M4 or
M5 screws (Fig. 5.2) appropriate for the weight of the unit and wall
material, use wall plugs. The bottom screw hole is only accessible after
removal of the bottom cover (Fig. 4). This bottom cover must remain
removed for the rest of this "Installation" chapter until instructed
otherwise.
Battery Connection
5.4
WARNING: The installation of this unit may only be undertaken by qualified personnel with appropriate
training. High voltages in and around the battery and unit can cause serious injury or death. This unit must be
installed in accordance with rules and regulations at the site of installation.
WARNING: Choose a suitable battery fuse as outlined in the chapter "Important Safety Information" , section
"OVERCURRENT PROTECTION FOR BATTERY" .
WARNING: Ensure the battery cables are sized according to the table below. Inadequate battery cables can
cause excessive heat or fire during operation.
Recommended battery cable cross-section, battery size and fuse / DC circuit breaker rating:
Any-Grid
PSW-H-5KW-
model
230/48V
Battery
35 ~ 50 mm²
cable cross-
AWG 0 ~ AWG 2
section
Nominal
battery
voltage
Min. battery
capacity
(lead-based)
Battery
140 Adc cont.
discharge
280 Adc surge
current
(5s)
capability
Fuse /
175 Adc,
breaker
min. 66 Vdc
rating
Steps to connect the battery:
1. WARNING: Ensure the battery cables are not yet connected to the battery.
CAUTION: Ensure none of the cable insulation is jammed in the ring terminal before crimping.
www.phocos.com
PSW-H-8KW-
PSW-H-5KW-
230/48V
120/48V
70 mm²
50 mm²,
AWG 2/0
AWG 0
48 Vdc
184 Adc cont.
115 Adc cont.
368 Adc surge
280 Adc surge
(5s)
(5s)
230 Adc, min.
175 Adc,
66 Vdc
min. 66 Vdc
All other models
Fig. 5.2: Mounting holes
PSW-H-
PSW-H-3KW-
6.5KW-
230/24V
120/48V
70 mm²
AWG 2/0
200 Ah
154 Adc
168 Adc cont.
cont.
336 Adc
308 Adc
surge (5s)
surge (5s)
200 Adc,
210 Adc, min.
min. 66
Vdc
Fig. 5.1: Minimum
distance to other objects
PSW-H-5KW-120/48V
PSW-H-6.5KW-120/48V
PSW-H-8KW-230/48V
PSW-H-3KW-
120/24V
35 ~ 50 mm²,
AWG 0 ~ AWG 2
24 Vdc
168 Adc cont.
336 Adc
surge (5s)
210 Adc, min.
33 Vdc
33 Vdc
8 |
