To define a daily time period in which a specific battery charging source priority is to be temporarily activated, follow
the steps below:
1. Press and hold
available priority orders are shown on the display (see chapter"Device Operation Settings"→ "Settings
menu 16" for an explanation):
2. From top to bottom the priorities shown in the screen represent:
a. Solar first ("CSO" for Charger Solar)
b. Solar and Utility ("SNU" for Solar and Utility)
c. Only Solar ("OSO")
3. Press either ,
a. = CSO
b. = SNU
c. = OSO
4. The selected priority order (CSO, SNU or OSO) is shown at the top of the screen. The middle shows the
starting time and the bottom shows the stopping time in full hours (24h notation). As an example for the
CSO priority:
5. Press to select the starting time (middle of screen), it will flash. Now press
starting time in 1-hour steps.Then, press
6. Press to select the ending time (bottom of screen), it will flash. Now press
ending time in 1-hour steps. Then, press
7. Now press to return to main screen.

Screen Views of Current Values

8.6
The screen views can be scrolled by pressing
www.phocos.com
for 3 seconds to enter the timer setting for the battery charger source priority.The three
or to enter one of the three selectable priorities:
or
to confirm the starting time, it will stop flashing.
to confirm the ending time, it will stop flashing.
to show current values in the following order:
or to change the
or to change the
