Maximum discharging current
This setting is important to
41
limit discharging current for
some battery types.
93 Erase all datalogger contents
94 Datalogger storage period
95 Time setting: minute
96 Time setting: hour
www.phocos.com
Disabled (Default)
Depending on the battery type used, its maximum discharge current
may be lower than what the Any-Grid unit requires to deliver its full
power to AC loads. If set to"Disabled" the unit will draw as much
current from the battery as necessary to supply the loads. If
overloaded by too much load power, settings menu 23 determines if
the unit may switch to the AC input by-pass to deliver more power or
protect itself by turning off permanently (until manual restart) or
temporarily (depends on settings menu 06).
If this setting is not "Disabled" then the unit will allow a maximum of
the set discharge current. If this limit is surpassed for more than 5
minutes, the unit will switch to the AC input by-pass temporarily to
provide more power to the loads. If no AC source is available, then the
unit will shut down for several seconds. After multiple failed attempts
the unit will turn off without reattempting to start the loads again.
Available values: Disabled and 30 ~ 120 Adc (up to 150 Adc for PSW-H-
8KW-230/48V) in 10 Adc increments for 48 Vdc model.
Available values: Disabled and 30 ~ 150 Adc in 10 Adc increments for
24 Vdc model.
No reset (Default)
10 days (Default)
120 A
Reset
The Any-Grid unit can store
measurement data with the
following frequency:
3 days: 20 entries per hour
5 days: 12 entries per hour
10 days: 6 entries per hour
20 days: 3 entries per hour
30 days: 2 entries per hour
60 days: 1 entry per hour
Once the memory is full, the oldest
entries are over-written.
Available values: 3, 5, 10, 20, 30 and
60 days.
Irrespective of this setting the unit
stores the last 100 error / warning
event codes.
Allows setting the current time in
minutes.
Available values: 00 ~ 59 minutes.
Allows setting the current time in
hours (24h notation).
Available values: 00 ~ 23 hours.
