1. Presentation

1.4 Relay communication card

1.5. J-BUS communication card

- Page 8
34400847FR/AA
40
42
43
43
41
44
5 6
4
2 3
1
B
A
45
46
47
(40) Screws to secure the cover
(41) Holes for securing the card in the card
40
compartment (2)
(42) Protection cover
(43) Openings for cables
(44) Output terminal block
43
41
43
(45) Input terminal block
(46) Screws to block cables
46
(47) RS485 connector
(48) RS232 connector
48
