Manual transfer to an out-of-phase alternate source

S1 S2
23 24 25
28 29
Q1 Q2
30 31
33 35
Q1BP
Q3
34
32
37
When the two sources are not in phase, it is
possible to force manual transfer using the
commands on the screen, after entering a
password.
1 - Enter the password (see section 3.5,
Customization).
2 - Follow the instructions provided on the
screen.
Q2BP
36
3. Operation
- Page 19
