1. Presentation
1.5 Relay communication card
1.6 JBus communication card
Page 10 -
34020113EN/AA
All manuals and user guides at all-guides.com
6
4 5
2 3
1
B
A
41
Screws to secure the cover
Card fixing holes
42
Protection cover
43
Openings for cables
44
Output terminal block
45
46
Input terminal block
Screws to block cables
47
48
RS232 connector
49
RS485 connector
