Intended Use

- The measuring system is designed for use in an industrial environment. It is used for
ƒ displacement, distance, movement and thickness measurement,
ƒ measuring the position of parts or machine components
- The measuring system must only be operated within the limits specified in the technical data.
The measuring system must only be used in such a way that no persons are endangered or machines are dam-
aged in the event of malfunction or total failure of the sensor.
Take additional precautions for safety and damage prevention in case of safety-related applications.

Proper Environment

- Sensor protection class:
- Operating temperature range: +5 ... +50 °C
- Temperature range (storage):
- Humidity:
- Ambient pressure:
- Shock (DIN EN 60068-2-27):
- Vibration (DIN EN 60068-2-6): 2 g / 20 ... 500 Hz in XY-axis, 10 cycles each

Glossary

SMR Start of measuring range
MR Measuring range
Minimum target thickness
Maximum target thickness
Page 4
IP64, front side
-20 ... +70 °C
5 ... 95% (non-condensing)
Atmospheric pressure
15 g / 6 ms in XY-axis, 1000 shocks each
see Technical Data, Operating Instructions
Sensor measuring range x Refractive index of target
MMR Mid of measuring range
EMR End of measuring range
General
confocalDT 2410/2415
