MICRO-EPSILON optoNCDT 2300 Assembly Instructions

Proper Environment
- Protection class: IP 65 (applies only when the sensor cable is plugged in)
- Operating temperature: 0 °C ... 50 °C (+32 up to +104 °F)
- Storage temperature: -20 °C ... 70 °C (-4 up to +158 °F)
- Humidity: 5 - 95 % (no condensation)
- Ambient pressure: Atmospheric pressure
Sensor Mounting, Diffuse Reflection
The optoNCDT 2300 sensor is an optical system for measurements with micrometer accuracy.
i
Make sure it is handled carefully when installing and operating!
Mount the sensor only to the existing holes on a flat surface. Clamps of any kind are not
permitted.
Mount the sensor by means of 3 screws type M4. The bearing surfaces surrounding the
fastening holes (through-holes) are slightly raised.
Diffuse Reflection, Dimensions and free space,
Measuring ranges 2/5/10/20/50/100 mm
97 (3.82)
30 (1.18)
89 (3.50)
4 4.5
(.16) (.18)
Laser off EtherCAT Ethernet
In range RUN
Midrange Power on
Error ERR
optoNCDT
LASER RADIATION
Do not stare into beam Class 2 Laser Product
IEC 60825-1: 2015-07
≤ 0 P 1mW; P P ≤ 1.2mW; t=0.5...542 µs
F=1.5...50kHz;  =670nm
3x Mounting
Diffuse reflection
holes ø4.5
for M4
MR = Measuring range
screws
10 (.39)
48 7 7
SMR = Start of measuring range
(1.89) 15
13.5 (.28)
(.59)
MBM = Midrange
(.53)
MBE = End of measuring range
Laser
MR 2 5 10 20 50
Limits for
free space
SMR 24 24 30 40 45
MMR 25 26.5 35 50 70
Keep this area free
EMR 26 29 40 60 95
from other light
sources and/or
Y 2 Y 1.5 3.5 6.5 10 23 33.5
their reflections
(.08)
Direct Reflection, Dimensions and free space,
Measuring ranges 2/10/20 mm
Mounting steps
Mounting holes
3x ø4.5 (dia. .18)
for M4 screws
Limits for free
space
The "State" LED illuminates yel-
low.
μ s
MR SMR + 0.5 MR alpha
100 2 25 20.5 °
5 26.5 20.5 °
70
10 35 17.5 °
correct
120
20 50 13.8 °
170
SMR = Start of measuring range
MR = Measuring range
In case of bore holes, blind holes, and
edges in the surface of moving targets
the sensor must be arranged in such a
way that the edges do not obscure the
laser spot.
Input and Output
Signal Sensor
Comment
Designation Pin
+ U 1 Supply voltage (11 ... 30 VDC)
b
System ground for supply and ground poten-
Ground 2
tial for RS422-level
optocoupler input, potential-free
+Laser on/off 3
Laser off: U ≤ 0,8 V (Low)
E
- Laser on/off 4
Laser on: 2,8 V ≤ U
Synchronous- respectively trigger signals,
Sync-in/out 5
Direct reflection 2
symmetrically, RS422-Pegel, terminating
resistor 120 Ohm switchable, input or output
selected depending on the synchronization
/Sync-in/out 6
2
Switch on the supply voltage mode
on the sensor.
RxD-RS422 7
Serial input RS422, symmetrically,
Watch the "State" LED on the /RxD-RS422 8 Internally terminated with 120 Ohm
top side of the sensor.
TxD-RS422 9
Serial output RS422, symmetrically
Position a shining or mirror-
/TxD-RS422 10
ing measuring object within
Tx - Ethernet 11
Ethernet output, potential-free
the measuring range.
/Tx - Ethernet 12
Move the fit-up aid between
Rx - Ethernet 13
sensor and measuring ob- Ethernet input, potential-free
/Rx - Ethernet 14
ject.
Screen Housing No galvanic connection to ground
1) Further cables are available optionaly.
Mount the sensor by means
2) In trigger operation the input is used for triggering.
of 3 screws type M4.
Plug connector: ODU MINI-SNAP , 14-pol., series B, dimension 2,
Remove the fit-up aid be-
code F, IP 68. Sensor round pin plug, view: Solder-pin side male cable
tween sensor and measuring
connector
object.
Supply Voltage, Nominal value: 24 V DC (11 ... 30 V, max. 150 mA).
1 Sensor PC2300-x/Y
11 ...
Pin Color
30 VDC
ILD 2300
1 white
2
2 brown
Laser on
Type 1 PC2300-x/Y
incorrect +U
B
white 1
(shadow)
ca. 5 mA
green 3
Laser off:
max.
U OUT < 0.8 V
Laser on: 30 V
2.8 V < U OUT < 30 V
yellow 4
Ground
brown
2
Cable PC2300-x/SUB-D
1
15-pol. Sub-D
1
9
2
10
≤ 30 V (High)
E
3
Proper Use
The optoNCDT 2300 system is designed for use in industrial and laboratory areas.
11
It is used for measuring displacement, distance, position and elongation for in-process quality con-
trol and dimensional testing
4
12 The sensor may only be operated within the limits specified in the technical data, see instruction
manual, Chap. 3.4. Use the sensor in such a way that in case of malfunctions or failure personnel or
5
machinery are not endangered.
13
Take additional precautions for safety and damage prevention for safety-related applications.
6
14 Warnings
7
Avoid unnecessary laser radiation to be exposed to the human body. Switch off the sensor for clean-
15 ing and maintenance, for system maintenance and repair if the sensor is integrated into a system.
Caution - use of controls or adjustments or performance of procedures other than those specified
Housing
may cause harm.
Connect the power supply and the display-/output device in accordance with the safety regulations
1 10
2 9 for electrical equipment. The power supply may not exceed the specified limits.
11
> Danger of injury. Damage to or destruction of the sensor.
3 12 14 8
13
4 7 Avoid continuous exposure to fluids on the sensor. Avoid exposure to aggressive materials (washing
5 6
agent, penetrating liquids or similar) on the sensor.
> Damage to or destruction of the sensor.
Avoid shock and vibration to the sensor. Protect the sensor cable against damage.
Supply
> Damage to or destruction of the sensor , failure of the measuring device.
Use supply voltage for measurement
instruments only. MICRO-EPSILON
Laser Class
+U
recommends using an optional available
B
power supply unit PS2020 for the sensor. The optoNCDT 2300 sensors operate with a semiconductor laser with a wavelength of 670 nm (vis-
Ground
ible/red ILD 2300-x) resp. 405 nm (visible/blue ILD 2300-xBL).
The following warning labels are attached to the cover (front and/or rear side) of the sensor housing:
i
If pin Pin 3 with +U and Pin 4 are
ILD 2300
B
not connected with ground, the
laser is off.
MICRO-EPSILON MESSTECHNIK
GmbH & Co. KG
IEC label
Königbacher Str. 15 · 94496 Ortenburg
www.micro-epsilon.com
*X9771234-A09*
X9771234-A091078HDR
Assembly Instructions
optoNCDT 2300
LASER RADIATION
LASER RADIATION
Do not stare into beam
Do not stare into beam
Class 2 Laser Product
THIS PRODUCT COMPLIES
Class 2 Laser Product
WITH FDA REGULATIONS IEC 60825-1: 2015-07
IEC 60825-1: 2015-07
21CFR 1040.10 AND 1040.11 P ≤ 1mW; P ≤ 1.2mW; t=0.5...542 s μ
P ≤ 1mW; P ≤ 1.2mW; t=0.5...542 s μ 0 P
0 P
F=1.5...50kHz;  =405nm
F=1.5...50kHz;  =670nm
Only for USA IEC label for ILD2300-x BL
Never deliberately look into the laser beam! Consciously close your eyes or
turn away immediately if ever the laser beam should hit your eyes.
