Direct fastening

Mount the sensor via three M3 screws.
max. 8
Screwing depth Screw
Minimum Maximum ISO 4762
mm mm 3 pc.
6 8 M3
Mounting conditions
IFD2410- 1 3
MR 1 3
SMR 15 25 35
A 56
B 33
C 150
D 27
Dimensions in mm
Page 6
1,0 Nm
Tightening torque
Nm
1.0
6 IFD2415- 1
6 MR 1
SMR 10
A 82
B 59
C 176 179
D 27
3 10
3 10
20 50
85 118
62 ---
212
Dimensional drawing IFD2410 / IFD2415
34 54
Dimension in mm (inch)
The bearing surfaces surrounding the mounting
holes are slightly raised.
Mechanical Fastening
48 (1.89)
28
±0.1
14
±0.1
free
D
aperture
confocalDT 2410/2415
63 (2.48)
confocal DT
29.5 (1.16)
